System And Components
Assembly
100%

131-3763 CONTROL & MTG GP-POWER TRAINS/N 7CS808-UP

Group No: 131-3763
Part NumberPart NameQty
6I14181 SPACER (8.2X12.7X28.7-MM THK)4
8T96552 MOUNT-ISOLATION8
9N08693 WASHER-HARD (8.8X25.5X2-MM THK)4
9S84134 WASHER-RETAINING (0.344X1.5X0.23-IN THK)4
11282425 INSULATOR2
16308366 PLATE AS1
1F0750NUT-WELD (3/8-16-THD)4
8T3612NUT-WELD (M8X1.25-THD)4
16316417 PLATE AS1
1F0750NUT-WELD (3/8-16-THD)2
8T3612NUT-WELD (M8X1.25-THD)4
16744118 PLATE1
16744149 PLATE AS1
9D6621NUT-WELD (10-24-THD)4
1F0750NUT-WELD (3/8-16-THD)1
4K9097NUT-WELD (5/16-18-THD)2
8T3612NUT-WELD (M8X1.25-THD)4
200537510 ELECTRONICS GP-MACHINE1
5M306211 BOLT (3/8-16X0.75-IN)9
5S737912 BOLT (3/8-16X0.875-IN)2
8T422413 WASHER-HARD (8.8X16X2-MM THK)1
8T489614 WASHER-HARD (10.2X18.5X2.5-MM THK)9
8T691215 BOLT (M8X1.25X50-MM)4
8T342616 CHANNEL-TRIM
8T342617 CHANNEL-TRIM
