System And Components
162-5322 WIRING GP-CABS/N 7CS280-807
Group No: 162-5322
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1770220 | 1 PANEL GP-CIRCUIT BREAKER | 1 | |
| 9X2042 | 2 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 | |
| 3E5239 | 3 RELAY AS (24-VOLT) | 9 | |
| 2N3479 | 4 SCREW (10-24X0.5-IN) | 14 | |
| 8T0328 | 5 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 6D3033 | 6 SCREW-SOCKET HEAD (4-40X0.5-IN) | 4 | |
| 6V9497 | 7 WASHER-HARD (3.2X6X0.5-MM THK) | 4 | |
| 6B4540 | 8 NUT (4-40-THD) | 4 | |
| 8C6354 | 9 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1654026 | 10 SWITCH AS-MAGNETIC (24-VOLT)(POWER) | 1 | |
| 4F2294 | 10A NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 6V8378 | 10B NUT (10-32-THD) | 2 | |
| 5S7349 | 11 BOLT (1/4-20X0.5-IN) | 9 | |
| 8T4205 | 12 WASHER-HARD (7.2X14.5X2-MM THK) | 11 | |
| 5P7854 | 13 CLIP (LOOP) | 1 | |
| 1656652 | 14 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 9D6621 | NUT-WELD (10-24-THD) | 4 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 12 | |
| 5M3062 | 15 BOLT (3/8-16X0.75-IN) | 11 | |
| 5P1075 | 16 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 1998046 | 17 HARNESS AS (TRANSMISSION) | 1 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 1080358 | 19 FLASHER AS (24-VOLT) | 1 | |
| 1035526 | 20 CONTROL GP-MONITOR (BACKLIGHT DIMMER) | 1 | |
| 5P2675 | 21 BOLT (1/4-20X1.75-IN) | 2 | |
| 9G9150 | 22 CLIP | 1 | |
| 1726142 | 23 HARNESS AS-RADIO | 1 | |
| 1246704 | 24 RESISTOR AS (ETHER SOLENOID LOAD)(START AID) | 1 | |
| 3T3047 | 25 CLIP AS | 1 | |
| 5T9327 | 26 GROMMET | 1 | |
| 3S2093 | 27 STRAP-CABLE | 32 | |
| 1630954 | 28 HARNESS AS-MONITOR (ELECTRONIC MONITORING SYSTEM) | 1 | |
| 1S0994 | 29 CLIP (LOOP) | 1 | |
| 5S7379 | 30 BOLT (3/8-16X0.875-IN) | 7 | |
| 1630842 | 31 PLATE (DIAGNOSTIC PANEL) | 1 | |
| 1631285 | 32 FILM-IDENTIFICATION (SERVICE)(ELECTRONIC TOOL CONNECTION) | 1 | |
| 1998039 | 33 HARNESS AS (MAIN) | 1 | |
| 8T9405 | 34 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 16 | |
| 8C9660 | 35 WASHER (4.6X7.9X0.8-MM THK) | 16 | |
| 1602445 | 36 SWITCH GP-PRESSURE (SECONDARY & PARKING BRAKE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1068704 | 37 SUPPRESSOR AS-ARC (KEY START SWITCH) | 1 | |
| 1068704 | 37A SUPPRESSOR AS-ARC (STOP LAMP) | 1 | |
| 1068704 | 37B SUPPRESSOR AS-ARC (HORN SOLENOID) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 9W3072 | 38 ANTENNA AS | 1 | |
| 9D4068 | 39 SWITCH-PUSH BUTTON (DOOR PUSH TYPE) | 1 | |
| 1191733 | 40 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 1305300 | 41 CLIP | 4 | |
| 4B4274 | 42 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 8C9678 | 43 LAMP GP-DOME (24-VOLT) | 1 | |
| 5L4507 | 44 SCREW-MACHINE (10-32X0.875-IN) | 3 | |
| 9F8125 | 45 LOCKWASHER | 3 | |
| 3T3045 | 46 CLIP AS | 1 | |
| 4E1411 | 47 BUSHING-TERMINAL | 1 | |
| 1850600 | 48 SENSOR GP-PRESSURE (AIR SYSTEM) | 1 | |
| 4P8134 | 49 CLIP (LADDER) | 6 | |
| 4P7581 | 50 CLIP (LADDER) | 1 | |
| 1437884 | 51 MODULE AS (INTERMITTENT WIPER) | 1 | |
| 1655957 | 52 SWITCH AS-ROCKER (24-VOLT)(HAZARD WARNING LIGHTS) | 1 | |
| 3P3839 | 53 GROMMET | 1 | |
| 9R7941 | 54 SOCKET AS | 1 | |
| 9R7980 | COVER | 1 | |
| 9R7935 | 55 WASHER-SHOULDER (18.5X27X2-MM THK) | 2 | |
| 7K1181 | 56 STRAP-CABLE | 30 | |
| 3E6328 | 57 ALARM GP (24-VOLT)(ACTION) | 1 | |
| 6T7695 | 58 SPEAKER AS-RADIO | 2 | |
| 1172932 | 59 CABLE AS-COAXIAL (RADIO) | 1 | |
| 6D4636 | 60 CLIP (LOOP) | 1 | |
| 1034977 | 61 SWITCH AS-PRESSURE (MANUAL RETARDER) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 9X0435 | 62 ADAPTER | 1 | |
| 3J7354 | 63 SEAL-O-RING | 1 | |
| 1532869 | 64 FILM-IDENTIFICATION (RELAY) | 1 | |
| 1328259 | 65 PLATE | 1 | |
| 5C9553 | 66 BOLT (M6X1X16-MM) | 2 | |
| 9X8256 | 67 WASHER (6.6X12X2-MM THK) | 2 | |
| 5C2890 | 68 NUT (M6X1-THD) | 2 | |
| 1160118 | 69 CLIP | 1 | |
| 3E2034 | 70 SWITCH AS-PRESSURE (SERVICE BRAKE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1667781 | 71 SWITCH AS-PRESSURE (STOP LAMP) | 1 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 3T3048 | 72 CLIP AS | 2 | |
| 1690169 | 73 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 1172311 | 74 SOCKET-AUXILIARY POWER (12-VOLT) | 1 | |
| 4M5281 | 75 BOLT (1/4-20X0.75-IN) | 2 | |
| 5P4115 | 76 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 1153069 | 77 CLIP AS-CONNECTING (3-PIN) | 1 |
