162-5322 WIRING GP-CABS/N 7CS808-UP

Group No: 162-5322
Part NumberPart NameQty
16677811 SWITCH AS-PRESSURE (STOP LIGHT)1
6V8378NUT (10-32-THD)2
8F1434LOCKWASHER2
3E20342 SWITCH AS-PRESSURE (SERVICE BRAKE)1
7N7779SOCKET-CONNECTOR (14-GA TO 18-GA)1
7N7780PIN-CONNECTOR (14-GA TO 18-GA)1
7N9738HOUSING-RECEPTACLE (14-GA TO 18-GA)1
3E52393 RELAY AS (24-VOLT)10
3E63284 ALARM GP (24-VOLT)(ACTION)1
3S20935 STRAP-CABLE37
3T30456 CLIP AS1
4E14117 BUSHING-TERMINAL1
5T93278 GROMMET1
6D30339 SCREW-SOCKET HEAD (4-40X0.5-IN)4
6T769510 SPEAKER AS-RADIO2
6V949711 WASHER-HARD (3.2X6X0.5-MM THK)4
7K118112 STRAP-CABLE28
8C635413 CAP-RECEPTACLE (ET CONNECTOR)1
8C967814 LAMP GP-DOME (24-VOLT)1
9D406815 SWITCH-PUSH BUTTON (DOOR)1
9F812516 LOCKWASHER3
9G915017 CLIP1
9R793518 WASHER-SHOULDER (18.5X27X2-MM THK)2
9R794119 SOCKET AS1
9R7980COVER1
9W307220 ANTENNA AS (RADIO)1
9X043521 ADAPTER1
103552622 CONTROL GP-MONITOR (BACKLIGHT DIMMER)1
106870423 SUPPRESSOR AS-ARC (KEY START)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
106870423A SUPPRESSOR AS-ARC (STOP LIGHT)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
106870423B SUPPRESSOR AS-ARC (HORN SOLENOID)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
108035824 FLASHER AS (24-VOLT)1
116011825 CLIP1
117231126 SOCKET-AUXILIARY POWER (12-VOLT)1
119173327 CONVERTER-POWER (24-VOLT TO 12-VOLT)1
124670428 RESISTOR AS (ETHER SOLENOID LOAD)(START AID)1
143788429 MODULE AS (INTERMITTENT WIPER)1
153286930 FILM-IDENTIFICATION (RELAY)1
160244531 SWITCH GP-PRESSURE (PARK, SECONDARY BRAKE)1
7N7779SOCKET-CONNECTOR (14-GA TO 18-GA)1
7N7780PIN-CONNECTOR (14-GA TO 18-GA)1
7N9738HOUSING-RECEPTACLE (14-GA TO 18-GA)1
163084232 PLATE (DIAGNOSTIC PANEL)1
163095433 HARNESS AS-MONITOR (ELECTRONIC MONITORING SYSTEM)1
165402634 SWITCH AS-MAGNETIC (24-VOLT)(MAIN RELAY)1
4F229434A NUT-JAM (5/16-24-THD)2
6V818634B NUT-FULL (5/16-24-THD)2
6V837834C NUT (10-32-THD)2
165595735 SWITCH AS-ROCKER (24-VOLT)(HAZARD WARNING LIGHTS)1
165665236 PLATE AS1
7T1099LINK3
1F0750NUT-WELD (3/8-16-THD)4
9D6621NUT-WELD (10-24-THD)4
9F6445NUT-WELD (1/4-20-THD)12
169016937 BRACKET AS1
1F0750NUT-WELD (3/8-16-THD)1
172614238 HARNESS AS-RADIO (OVERHEAD)1
1028802KIT-RECEPTACLE (2-PIN)1
1028805KIT-RECEPTACLE (6-PIN)1
1028801KIT-RECEPTACLE (12-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
1552274KIT-CONNECTING PLUG (6-PIN)1
1552265KIT-CONNECTING PLUG (8-PIN)1
177022039 PANEL GP-CIRCUIT BREAKER1
185060040 SENSOR GP-PRESSURE (AIR SYSTEM)1
225832741 HARNESS AS-CAB1
1028803KIT-RECEPTACLE (3-PIN)1
1028802KIT-RECEPTACLE (2-PIN)1
1028805KIT-RECEPTACLE (6-PIN)1
1028801KIT-RECEPTACLE (12-PIN)
1552260KIT-CONNECTING PLUG (3-PIN)1
1552255KIT-CONNECTING PLUG (12-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
1552274KIT-CONNECTING PLUG (6-PIN)1
103497742 SWITCH AS-PRESSURE (MANUAL RETARDER)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)1
115306943 CLIP AS-CONNECTING (3-PIN)1
117293244 CABLE AS-COAXIAL1
130530045 CLIP4
132825946 PLATE1
163128547 FILM-IDENTIFICATION (SERVICE)1
1S099448 CLIP (LOOP)1
2N347949 SCREW (10-24X0.5-IN)14
3J735450 SEAL-O-RING1
3P383951 GROMMET1
3T304852 CLIP AS2
4B427453 WASHER (5.5X13X1.2-MM THK)2
4M528154 BOLT (1/4-20X0.75-IN)2
4P758155 CLIP (LADDER)1
4P813456 CLIP (LADDER)6
5C289057 NUT (M6X1-THD)2
5C955358 BOLT (M6X1X16-MM)2
5L450759 SCREW-MACHINE (10-32X0.875-IN)3
5M306260 BOLT (3/8-16X0.75-IN)11
5P107561 WASHER-HARD (10.2X22.5X3-MM THK)8
5P267562 BOLT (1/4-20X1.75-IN)2
5P411563 WASHER-HARD (7.2X19X2-MM THK)2
5P785464 CLIP (LOOP)1
5S734965 BOLT (1/4-20X0.5-IN)10
5S737966 BOLT (3/8-16X0.875-IN)7
6B454067 NUT (4-40-THD)4
6D463668 CLIP (LOOP)1
8C966069 WASHER (4.6X7.9X0.8-MM THK)16
8T032870 WASHER-HARD (5.5X10X1-MM THK)4
8T420571 WASHER-HARD (7.2X14.5X2-MM THK)12
8T489672 WASHER-HARD (10.2X18.5X2.5-MM THK)10
8T940573 BOLT-SOCKET HEAD (M4X0.7X16-MM)16
9X204274 SCREW-TRUSS HEAD (M6X1X12-MM)8
9X825675 WASHER (6.6X12X2-MM THK)2
1028802KIT-RECEPTACLE (2-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
