System And Components
9G-9625 GEAR GP-TRANSFER -INPUTS/N 4FY1-99999
Group No: 9G-9625
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1566 | 1 BOLT (5/8-11X1.5-IN) | 2 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 6P2515 | 2 RING AS-LIFTING | 1 | |
| 1K0958 | CLAMP-CENTER | 1 | |
| 8H7521 | 3 SEAL-O-RING | 1 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 4 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 0S1587 | 6 BOLT (1/2-13X1.75-IN) | 17 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 8P3795 | 7 SCREEN-SUCTION | 1 | |
| 8P3251 | 8 COVER AS | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 2 | |
| 7S2962 | WASHER-SPRING (52.3X82.5X9.1-MM THK) | 1 | |
| 4S8603 | 9 SCREEN GP-MAGNETIC (TRANSMISSION) | 1 | |
| 8M7160 | MAGNET | 3 | |
| 7G1152 | 10 TUBE AS | 1 | |
| 5K9243 | 11 ELBOW-FLARED | 1 | |
| 2A4639 | 12 BOLT (3/8-16X1.625-IN) | 1 | |
| 0T0102 | 13 BOLT (3/8-16X0.625-IN) | 1 | |
| 2B2404 | 14 CLIP | 1 | |
| 9G9959 | 15 CAGE-BEARING | 1 | |
| 0S1588 | 16 BOLT (3/8-16X1.25-IN) | 13 | |
| 3P8146 | 17 CAGE-BEARING | 1 | |
| 8T0377 | 18 BOLT-12 POINT HEAD (5/8-18X5.5-IN) | 1 | |
| 4D3704 | WASHER-HARD (17X30X5-MM THK) | 1 | |
| 6Y8972 | 19 YOKE | 1 | |
| 6B2882 | 20 SPACER (0.406X0.75X0.312-IN THK) | 1 | |
| 1428075 | 21 SEAL-LIP TYPE | 1 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 10 | |
| 6N9340 | SPACER (0.391X0.688X1.12-IN THK) | 10 | |
| 6M5218 | 23 SEAL-O-RING | 1 | |
| 3P8147 | 24 SHIM PACK (INCLUDES 9-SHIMS) | 1 | |
| 2M3818 | 25 SEAL-O-RING | 1 | |
| 7G1151 | 26 CASE-TRANSFER GEAR | 1 | |
| 1084879 | 27 GEAR-TRANSFER (71-TEETH) | 1 | |
| 6Y9220 | 28 RETAINER AS | 1 | |
| 2K3455 | 29 PIN-SPRING | 2 | |
| 1P3934 | 30 CUP-BEARING | 2 | |
| 1P3935 | CONE-BEARING | 2 | |
| 7G1157 | 31 SHIM PACK (INCLUDES 22-SHIMS) | 1 | |
| 0300060 | 32 CUP-BEARING (TAPERED ROLLER) | 2 | |
| 1777886 | CONE | 2 | |
| 1084880 | 33 GEAR-TRANSFER (54-TEETH) | 1 | |
| 5S7779 | 34 RING-RETAINING | 1 |
