System And Components
108-1868 TORQUE CONVERTER GPS/N 80M1046-UP
Group No: 108-1868
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1T2046 | 1 TORQUE CONVERTER GP (FREEWHEEL & LOCKUP) | 1 | |
| 0S1585 | 2 BOLT (1/2-13X1.5-IN) | 13 | |
| 5P8245 | 3 WASHER-HARD (13.5X25.5X3-MM THK) | 13 | |
| 1467312 | 4 SEAL-O-RING | 1 | |
| 1074036 | 5 HOUSING AS-TORQUE CONVERTER | 1 | |
| 8T4896 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 8H7521 | 10 SEAL-O-RING | 1 | |
| 8P3795 | 11 SCREEN-SUCTION (POWER TRAIN) | 1 | |
| 8T2502 | 12 BOLT (3/8-16X1.125-IN) | 19 | |
| 1453187 | 13 COVER-GAUGE | 1 | |
| 1453188 | 14 GASKET | 1 | |
| 1453189 | 15 SUPPORT AS | 1 | |
| 1453192 | 16 DEFLECTOR | 1 | |
| 1290987 | 17 DRAIN AS | 1 | |
| 8F0212 | 18 SEAL-O-RING | 1 | |
| 3H1461 | 19 SEAL-O-RING | 1 | |
| 1754946 | 20 PLUG-DRAIN | 1 | |
| 1467311 | 21 SEAL-O-RING | 1 | |
| 8P3251 | 22 COVER AS | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 2 | |
| 7S2962 | WASHER-SPRING (52.3X82.5X9.1-MM THK) | 1 | |
| 4L6454 | 23 BOLT (3/8-16X1-IN) | 4 | |
| 5F8000 | 24 SEAL-O-RING | 1 | |
| 1139556 | 25 TUBE AS-BAFFLE | 1 | |
| 1139558 | 26 GASKET | 1 | |
| 6J1080 | 27 GROMMET | 2 | |
| 8T2561 | 28 WASHER-HARD (10.5X28.5X5-MM THK) | 8 | |
| 8T4133 | 29 NUT (M10X1.5-THD) | 8 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 8 | |
| 1039603 | 31 GAUGE-SIGHT | 2 | |
| 1403609 | 32 PLATE | 1 | |
| 1412932 | 33 PLATE | 1 |
