128-2352 VALVE GP-LOCKUP CLUTCH & SOLS/N 80M1046-1773

Group No: 128-2352

Part Number	Part Name	Qty
6I9475	1 BODY AS-VALVE	1
5H8985	PIN-SPRING	1
8E8439	DOWEL	1
9S8008	2 PLUG (1-1/16-12-THD)	2
3D2824	3 SEAL-O-RING	2
9S8001	4 PLUG (5/16-24-THD)	6
4J7533	5 SEAL-O-RING	6
7X1120	6 VALVE GP-SOLENOID (LOCKUP CLUTCH)	1
3J1907	7 SEAL-O-RING	4
6V3965	8 FITTING (QUICK DISCONNECT)	1
6V0852	9 CAP-DUST	1
9S8004	10 PLUG (9/16-18-THD)	3
9G9150	11 CLIP	1
5L9018	12 BOLT-SOCKET HEAD (1/4-20X1.75-IN)	2
6Y4539	13 COVER	1
0S1618	14 BOLT (5/16-18X1-IN)	6
9M1974	15 WASHER-HARD (8.8X16X2-MM THK)	4
2S2182	16 SEAL-O-RING	1
6Y7267	17 SPRING	1
8E6144	18 SPRING	1
6Y4540	19 BODY	1
9J1330	20 SHIM (0.787-MM THK)	2
2S0675	21 SPACER (0.4-MM THK)	2
8J4452	22 SHIM (0.12-MM THK)	2
6Y4541	23 PISTON-SELECTOR	1
6Y4542	24 PISTON-LOAD	1
2B2695	25 BOLT (5/16-18X0.875-IN)	2
6Y4538	26 COVER	1
8M4986	27 SEAL-O-RING	1
8M5127	28 SEAL-O-RING	1
8P9739	29 ORIFICE-CASCADE	1
9D7884	30 SPRING	1
1282880	31 STOP	1
6Y8048	32 SPOOL AS	1
1S1636	RETAINER	1
1S1638	RING-RETAINING	1
4B9880	BALL	1
4M2381	SPRING	1
9P0683	33 SPRING	1
5M2504	34 SLUG	2
9W6964	35 VALVE AS-EXHAUST	1
3F3152	BALL	1
8N4173	DOWEL	1
9S8003	36 PLUG (1/2-20-THD)	1
1J9671	37 SEAL-O-RING	1
5J2721	38 SHIM (0.13-MM THK)	2
6J3993	39 SHIM (0.25-MM THK)	2
5J1036	40 SHIM (0.8-MM THK)	2
6T3724	41 COVER	1
9W7410	42 SPRING	1
9P0656	43 SPOOL AS	1
1S1636	RETAINER	1
1S1638	RING-RETAINING	1
4B9880	BALL	1
4M2381	SPRING	1
8M4446	44 SEAL-O-RING	1
