System And Components
128-2352 VALVE GP-LOCKUP CLUTCH & SOLS/N 80M1774-UP
Group No: 128-2352
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I9475 | 1 BODY AS-VALVE | 1 | |
| 5H8985 | PIN-SPRING | 1 | |
| 8E8439 | DOWEL | 1 | |
| 3159859 | 2 PLUG AS | 2 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218641 | 4 PLUG AS | 7 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3023809 | 6 VALVE GP-SOLENOID (TORQUE CONVERTER LOCKUP CLUTCH) | 1 | |
| 1645567 | 8 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V0852 | 9 CAP-DUST | 1 | |
| 1833407 | 10 PLUG AS | 3 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5L9018 | 12 BOLT-SOCKET HEAD (1/4-20X1.75-IN) | 2 | |
| 6Y4539 | 13 COVER | 1 | |
| 0S1618 | 14 BOLT (5/16-18X1-IN) | 6 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 6V6353 | 16 SEAL-O-RING | 1 | |
| 6Y7267 | 17 SPRING | 1 | |
| 8E6144 | 18 SPRING | 1 | |
| 6Y4540 | 19 BODY | 1 | |
| 9J1330 | 20 SHIM (0.787-MM THK) | 2 | |
| 2S0675 | 21 SPACER (0.4-MM THK) | 2 | |
| 8J4452 | 22 SHIM (0.12-MM THK) | 2 | |
| 6Y4541 | 23 PISTON-SELECTOR | 1 | |
| 6Y4542 | 24 PISTON-LOAD | 1 | |
| 2B2695 | 25 BOLT (5/16-18X0.875-IN) | 2 | |
| 6Y4538 | 26 COVER | 1 | |
| 0617540 | 27 SEAL-O-RING | 1 | |
| 8L2777 | 28 SEAL-O-RING | 1 | |
| 3706346 | 29 ORIFICE AS | 1 | |
| 9D7884 | 30 SPRING | 1 | |
| 1282880 | 31 STOP | 1 | |
| 6Y8048 | 32 SPOOL AS | 1 | |
| 1S1636 | RETAINER | 1 | |
| 1S1638 | RING-RETAINING | 1 | |
| 4B9880 | BALL | 1 | |
| 4M2381 | SPRING | 1 | |
| 9P0683 | 33 SPRING | 1 | |
| 5M2504 | 34 SLUG | 2 | |
| 9W6964 | 35 VALVE AS-EXHAUST | 1 | |
| 3F3152 | BALL | 1 | |
| 8N4173 | DOWEL | 1 | |
| 3218642 | 36 PLUG AS | 1 | |
| 9S8803 | PLATE-TRANSMISSION NUMBER | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 5J2721 | 38 SHIM (0.13-MM THK) | 2 | |
| 6J3993 | 39 SHIM (0.25-MM THK) | 2 | |
| 5J1036 | 40 SHIM (0.8-MM THK) | 2 | |
| 6T3724 | 41 COVER | 1 | |
| 9W7410 | 42 SPRING | 1 | |
| 9P0656 | 43 SPOOL AS | 1 | |
| 1S1636 | RETAINER | 1 | |
| 1S1638 | RING-RETAINING | 1 | |
| 4B9880 | BALL | 1 | |
| 4M2381 | SPRING | 1 | |
| 6V3683 | 44 SEAL-O-RING | 1 | |
| 9G9150 | 45 CLIP | 1 | |
| 3159835 | 46 ELBOW AS | 1 | |
| 6V0484 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 |
