System And Components
3T-1512 VALVE GP-SELECTOR & PRESS CONT -TRANSMISSIONS/N 4FY1-UP
Group No: 3T-1512
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7G3472 | 1 BODY-SELECTOR | 1 | |
| 1P9620 | 2 RING-RETAINING | 2 | |
| 1625802 | 3 CAM-DETENT | 1 | |
| 4D0514 | 4 PLUG-PIPE | 2 | |
| 8E4094 | 5 SUPPORT AS-SPRING | 1 | |
| 8H9208 | 5A DOWEL | 2 | |
| 1450109 | 6 SPOOL AS | 1 | |
| 1470045 | 6A PIN-SPRING | 1 | |
| 4B9880 | 6B BALL | 1 | |
| 4M2381 | 6C SPRING | 1 | |
| 2L6726 | 6D RING-RETAINING | 1 | |
| 6T5411 | 6E SLUG | 1 | |
| 5P7701 | 7 SEAL-O-RING | 1 | |
| 9P0673 | 8 VALVE-RELIEF | 1 | |
| 9P0674 | 10 BODY | 1 | |
| 3T9920 | 11 SPRING | 1 | |
| 9P0672 | 12 CAP | 1 | |
| 1450106 | 13 SPACER (3.18X20.62X0.9-MM THK) | 3 | |
| 1450105 | 14 SPACER (3.18X20.62X0.25-MM THK) | 5 | |
| 6T5409 | 15 SPRING | 1 | |
| 8M6402 | 16 SPRING | 1 | |
| 2S0696 | 17 DOWEL | 1 | |
| 5M3492 | 18 SPACER (3.18X19.05X0.25-MM THK) | 3 | |
| 7M1397 | 19 SPACER (3.18X19.05X0.9-MM THK) | 4 | |
| 6T3177 | 20 SPRING | 1 | |
| 6T3696 | 21 SPOOL AS-REDUCING | 1 | |
| 1470045 | 21A PIN-SPRING | 1 | |
| 5M9548 | 21B SPRING | 1 | |
| 8M2537 | 21C RETAINER | 1 | |
| 1L3162 | 21D RING-RETAINING | 1 | |
| 8M1078 | 21E CHECK | 1 | |
| 5M6214 | 22 PLUG (1/8-27 PTF) | 1 | |
| 8P9852 | 23 COVER | 1 | |
| 3E6747 | 24 SEAL-O-RING | 1 | |
| 8E7190 | 25 COVER AS | 1 | |
| 6T3115 | 26 SPOOL AS | 1 | |
| 1H4142 | 26A RING-RETAINING | 1 | |
| 7T6175 | 26B SEAT | 1 | |
| 5H6005 | 26C SEAL-O-RING | 1 | |
| 4B9880 | 26D BALL | 1 | |
| 4M2381 | 26E SPRING | 1 | |
| 1767368 | 27 SPOOL AS-ROTARY | 1 | |
| 9P9650 | 27A DOWEL | 1 | |
| 3T5219 | 27B PIN | 1 | |
| 3J1907 | 27C SEAL-O-RING | 1 | |
| 6T7640 | 27D SCREEN-FILTER (TRANSMISSION CONTROL) | 1 | |
| 1450108 | 28 STOP | 1 | |
| 4213135 | 29 PIN-SPRING | 1 | |
| 9S8413 | 31 WASHER-RETAINING (0.344X1.5X0.23-IN THK) | 1 | |
| 0314630 | 32 BOLT-LOCKING (5/16-18X0.75-IN) | 1 | |
| 1293033 | 33 SPRING AS | 2 | |
| 3G3916 | RING-RETAINING | 1 | |
| 9W7009 | RETAINER-BEARING | 2 | |
| 6V5701 | BEARING AS-NEEDLE | 2 | |
| 9W7011 | PIN | 1 | |
| 9M1974 | 34 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 4B3388 | 35 BOLT (5/16-18X1.125-IN) | 4 | |
| 7L6210 | 36 BOLT-LOCATING (5/16-18X1-IN) | 2 | |
| 9P0652 | 37 RETAINER | 2 | |
| 1B7182 | 40 BOLT (5/16-18X1.25-IN) | 1 | |
| 1D4539 | 41 BOLT (5/16-18X2.5-IN) | 1 | |
| 1450107 | 42 SPACER (3.18X20.62X1.6-MM THK) | 3 |
