System And Components
3T-1511 VALVE GP-TRANSMISSION CONTROLS/N 4FY1-UP
Group No: 3T-1511
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T9791 | 1 COVER | 1 | |
| 4F3508 | 2 BOLT (5/16-18X6.5-IN) | 5 | |
| 8F8544 | 3 BOLT (3/8-16X6.25-IN) | 1 | |
| 3T1513 | 4 VALVE GP-PRESSURE CONTROL (CLUTCH OIL FLOW) | 1 | |
| 3T1512 | 5 VALVE GP-SELECTOR & PRESS CONT (TRANSMISSION) | 1 | |
| 3T0391 | 6 PLATE | 1 | |
| 3T0987 | 7 MANIFOLD | 1 | |
| 1D4541 | 8 BOLT (5/16-18X3-IN) | 12 | |
| 0S1618 | 9 BOLT (5/16-18X1-IN) | 1 | |
| 9W4119 | 10 ACTUATOR GP-ROTARY (TRANSMISSION CONTROL VALVE) | 1 | |
| 4B3903 | 11 BOLT (5/16-18X4-IN) | 2 | |
| 1F4111 | 12 BOLT (5/16-18X3.5-IN) | 1 | |
| 9M1974 | 13 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 6V3965 | 15 FITTING (QUICK DISCONNECT) | 7 | |
| 3J1907 | SEAL-O-RING | 7 |
