Assembly
100%

136-1810 FENDER GPS/N 7CS1-UP

Group No: 136-1810
Part NumberPart NameQty
12829971 FENDER AS1
1F0748NUT-WELD (1/2-13-THD)3
7F5462LUG (20-MM THK)1
7T1099LINK1
8W1040LUG (6-MM THK)2
9D3599PIPE1
5S73792 BOLT (3/8-16X0.875-IN)9
5P10753 WASHER-HARD (10.2X22.5X3-MM THK)38
14333814 GUARD AS1
1F0750NUT-WELD (3/8-16-THD)5
4L64545 BOLT (3/8-16X1-IN)16
8T25616 WASHER-HARD (10.5X28.5X5-MM THK)18
6V88017 NUT (3/8-16-THD)2
8W60628 DEFLECTOR1
8W60639 STRIP1
9D785710 GUARD AS1
1F0750NUT-WELD (3/8-16-THD)5
6G321811 GUARD2
5M306212 BOLT (3/8-16X0.75-IN)10
2G225813 STRIP1
8W638714 GUARD1
2G342415 STRIP2
5T655316 PLATE1
8T250217 BOLT (3/8-16X1.125-IN)10
9B723718 BOLT (3/8-16X1.25-IN)11
137583419 PLATE1
5P222820 BOLT (1/2-13X1-IN)2
8T422321 WASHER-HARD (13.5X25.5X3-MM THK)2
8W606422 STRIP1
