System And Components
136-1799 HANDRAIL GP -PLATFORMS/N 7CS1-493
Group No: 136-1799
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1430025 | 1 RAIL AS | 1 | |
| 0T0883 | 2 WASHER (0.531X1X0.065-IN THK) | 2 | |
| 2G2345 | 3 BRACKET | 1 | |
| 8T4896 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 3B4615 | 5 PIN-COTTER | 2 | |
| 4L6454 | 6 BOLT (3/8-16X1-IN) | 20 | |
| 5D3887 | 7 ROD | 1 | |
| 5K4549 | 8 U-BOLT (1/4-20X2.12-IN) | 2 | |
| 5P1075 | 9 WASHER-HARD (10.2X22.5X3-MM THK) | 18 | |
| 9D4721 | 10 RAIL AS | 1 | |
| 6F8499 | 11 SPRING | 1 | |
| 6V8185 | 12 NUT (1/4-20-THD) | 4 | |
| 8T4205 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4223 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 1537094 | 15 BRACKET | 1 | |
| 8T8917 | 16 BOLT (1/2-13X1.25-IN) | 1 | |
| 9B7237 | 17 BOLT (3/8-16X1.25-IN) | 2 |
