System And Components
136-1809 HOOD GP-TRUCKS/N 7CS855-UP
Group No: 136-1809
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9D8350 | 1 GUIDE AS | 1 | |
| 5J3463 | BAR | 1 | |
| 8T9377 | 2 BOLT (3/8-16X2.25-IN) | 4 | |
| 8T2561 | 3 WASHER-HARD (10.5X28.5X5-MM THK) | 28 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 3B4627 | 5 PIN-COTTER | 1 | |
| 2G6324 | 6 PROP AS | 1 | |
| 1A1999 | DOWEL | 1 | |
| 2G9804 | 7 PLATE AS | 1 | |
| 1F0750 | 8 NUT-WELD (3/8-16-THD) | 4 | |
| 1289754 | 9 BRACKET AS | 1 | |
| 7T1099 | LINK | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 5S7379 | 10 BOLT (3/8-16X0.875-IN) | 20 | |
| 8T4896 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9M3835 | 12 LATCH-RUBBER | 4 | |
| 5T3865 | 13 BRACKET AS | 1 | |
| 1J8499 | WASHER (0.15-MM THK) | 2 | |
| 9M2760 | 14 ANCHOR | 4 | |
| 5S7349 | 15 BOLT (1/4-20X0.5-IN) | 8 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 1283135 | 16 BRACKET AS | 1 | |
| 8D3508 | BOSS (3/8-16X1-IN) | 1 | |
| 9F6445 | 17 NUT-WELD (1/4-20-THD) | 4 | |
| 2G9399 | 18 ROD | 1 | |
| 3B4615 | PIN-COTTER | 1 | |
| 0T0883 | WASHER (0.531X1X0.065-IN THK) | 1 | |
| 6F8499 | SPRING | 1 | |
| 6D8667 | 19 HANDHOLD | 2 | |
| 5S7382 | 20 BOLT (3/8-16X1.375-IN) | 14 | |
| 6V8801 | 21 NUT (3/8-16-THD) | 14 | |
| 8T4226 | 24 WASHER-PLATED (10.5X45X3-MM THK) | 8 | |
| 8W9189 | 25 HINGE | 2 | |
| 9D8388 | 26 HINGE-HOOD | 1 | |
| 1430808 | 27 HOOD AS (REAR) | 1 | |
| 7D8635 | 28 RIVET | 4 | |
| 9M2307 | 29 WASHER (5.2X19X2-MM THK) | 10 | |
| 1038093 | 30 RIVET-POP | 6 | |
| 9M3837 | 31 BRACKET-CATCH | 2 | |
| 9B7237 | BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6V8801 | NUT (3/8-16-THD) | 7 | |
| 4L6454 | 33 BOLT (3/8-16X1-IN) | 3 | |
| 8T2561 | WASHER-HARD (10.5X28.5X5-MM THK) | 3 | |
| 1078347 | 34 COVER AS | 1 | |
| 1078349 | 35 PLATE | 1 | |
| 1078348 | 36 HINGE | 1 | |
| 1061865 | 37 LATCH AS-DOOR | 1 | |
| 1283136 | 38 HOOD AS (FRONT) | 1 | |
| 9M2307 | 39 WASHER (5.2X19X2-MM THK) | 4 | |
| 7D8635 | RIVET | 4 | |
| 9M3837 | 40 BRACKET-CATCH | 2 | |
| 9B7237 | 41 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6V8801 | NUT (3/8-16-THD) | 4 | |
| 8T2502 | 42 BOLT (3/8-16X1.125-IN) | 4 | |
| 5P5969 | 43 SEAL (.6M) | ||
| 5G0817 | 44 BUMPER-CONICAL | 1 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 1 | |
| 2M5795 | 45 PIN-CLEVIS | 4 | |
| 3B4607 | PIN-COTTER | 4 | |
| 8H5305 | WASHER (0.266X0.5X0.105-IN THK) | 4 | |
| 9D7924 | 46 MOUNTING AS | 4 | |
| 5P1075 | 47 WASHER-HARD (10.2X22.5X3-MM THK) | 16 |
