System And Components
135-9413 LINES GP-HYDRAULIC OIL COOLERS/N 7CS1-UP
Group No: 135-9413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1K2617 | 1 SPACER (1-13/32-IN THK) | 1 | |
| 6G1444 | 2 ADAPTER | 1 | |
| 6G7264 | 3 BRACKET | 2 | |
| 6G7270 | 4 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6G8983 | 5 ADAPTER | 1 | |
| 7D4071 | 6 CLAMP | 1 | |
| 7D4086 | 7 HOSE AS | 1 | |
| 8W5566 | 8 ADAPTER | 1 | |
| 1351841 | 9 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1387839 | 10 HOSE AS | 1 | |
| 1387853 | 11 HOSE AS | 1 | |
| 1387855 | 12 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1989563 | 13 HOSE AS | 1 | |
| 1406022 | 14 HOSE AS | 1 | |
| 1407533 | 15 HOSE AS | 1 | |
| 1494134 | 16 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1503065 | 17 ELBOW AS | 1 | |
| 6V0484 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1645567 | 18 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1670799 | 19 TUBE AS | 1 | |
| 1488347 | 20 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488360 | 21 ELBOW AS | 1 | |
| 6V9182 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488411 | 22 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1P3707 | 23 SEAL-RECTANGULAR | 1 | |
| 1P4582 | 24 FLANGE-HALF | 14 | |
| 4J0527 | 25 SEAL-O-RING | 12 | |
| 4J0528 | 26 SEAL-O-RING | 4 | |
| 4L6454 | 27 BOLT (3/8-16X1-IN) | 1 | |
| 4L9337 | 28 BOLT (3/8-16X1.5-IN) | 2 | |
| 4S1253 | 29 PLATE | 1 | |
| 5M3062 | 30 BOLT (3/8-16X0.75-IN) | 4 | |
| 5P1075 | 31 WASHER-HARD (10.2X22.5X3-MM THK) | 10 | |
| 5P2424 | 32 BOLT (1/2-13X2.25-IN) | 6 | |
| 5P7468 | 33 CLIP (SLOT) | 2 | |
| 5P7469 | 34 CLIP (TAB) | 2 | |
| 5P7470 | 35 CLIP (SLOT) | 4 | |
| 5P7471 | 36 CLIP (TAB) | 4 | |
| 6V0852 | 37 CAP-DUST | 1 | |
| 6V1889 | 38 CLIP (LOOP) | 1 | |
| 6V8801 | 39 NUT (3/8-16-THD) | 3 | |
| 7X0326 | 40 BOLT (1/2-13X3-IN) | 6 | |
| 7X0328 | 41 BOLT (1/2-13X3.5-IN) | 4 | |
| 8T2502 | 42 BOLT (3/8-16X1.125-IN) | 2 | |
| 8T2885 | 43 SEAL-RECTANGULAR | 1 | |
| 8T4223 | 44 WASHER-HARD (13.5X25.5X3-MM THK) | 53 | |
| 8T4896 | 45 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T8917 | 46 BOLT (1/2-13X1.25-IN) | 1 | |
| 8T8919 | 47 BOLT (1/2-13X1.75-IN) | 26 | |
| 8T8920 | 48 BOLT (1/2-13X3.25-IN) | 4 | |
| 8T9101 | 49 BOLT (3/8-16X2.75-IN) | 1 | |
| 8T9389 | 50 BOLT (1/2-13X2.75-IN) | 2 | |
| 8T9391 | 51 BOLT (1/2-13X3.75-IN) | 4 | |
| 9X8872 | 52 BOLT-LOCKING (3/8-16X0.875-IN) | 1 |
