System And Components
111-8399 PUMP GP-GEAR -BRAKE RELEASE, HOISTS/N 80M1046-UP
Group No: 111-8399
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D6648 | 1 RING-RETAINING | 1 | |
| 2495320 | 2 GEAR-IDLER (10-TEETH) | 1 | |
| 1464208 | 3 FLANGE AS | 1 | |
| 6J2386 | 4 DOWEL | 8 | |
| 1487080 | 5 BODY AS | 1 | |
| 4T9298 | 6 BUSHING | 4 | |
| 1487082 | 7 PLATE AS | 1 | |
| 1487081 | 8 BODY AS | 1 | |
| 6V7350 | 9 SEAL-O-RING | 2 | |
| 3E6799 | 10 SEAL-O-RING | 1 | |
| 5S1522 | 11 RING-SNAP | 2 | |
| 1487084 | 12 GEAR-DRIVE (14-TEETH) | 1 | |
| 4T9426 | 13 PLATE-ISOLATION | 1 | |
| 5E8771 | 14 SEAL-O-RING | 1 | |
| 4T9425 | 15 PLATE-ISOLATION | 1 | |
| 4T8729 | 16 PLATE-PRESSURE | 2 | |
| 9N1619 | 17 SEAL-O-RING | 1 | |
| 6E2943 | 18 PLUG | 1 | |
| 9T5360 | 19 PLATE-PRESSURE | 1 | |
| 6E4764 | 20 PLATE-PRESSURE | 1 | |
| 1489663 | 21 STUD (1/2-20X0.7-IN, 1/2-13X1-IN) | 4 | |
| 7X3374 | 22 NUT-FULL (1/2-20-THD) | 4 | |
| 5P7213 | 23 WASHER-HARD (13.5X20.5X2-MM THK) | 12 | |
| 9X8880 | 24 BOLT (5/8-11X2-IN) | 8 | |
| 9T1267 | 25 GEAR-IDLER | 1 | |
| 2495321 | 26 GEAR-DRIVE | 1 | |
| 1654427 | 27 BUSHING | 4 | |
| 1553167 | 28 SEAL-LIP TYPE | 2 | |
| 1700955 | 29 COUPLING | 1 | |
| 7J4772 | 30 COUPLING-SPLINE | 1 | |
| 1625215 | 31 PLATE-ADAPTER | 1 | |
| 1627452 | 32 BOLT-SOCKET HEAD (1/2-13X5.5-IN) | 8 | |
| 6V0852 | 33 CAP-DUST | 1 | |
| 6V3965 | 34 FITTING (QUICK DISCONNECT) | 1 | |
| 0336042 | 35 SEAL-O-RING | 1 | |
| 1487087 | KIT-SEAL (HOIST, BRAKE RELEASE) | 1 |
