System And Components
135-6616 VALVE GP-PUMP CONTROL -PRESSURE, FLOW COMPENSATORS/N 80M1046-3168
Group No: 135-6616
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6E6528 | 1 SEAL | 6 | |
| 6E6527 | 2 PLUG | 2 | |
| 6E3268 | 3 RETAINER-SPRING | 1 | |
| 6E3275 | 4 SPRING | 1 | |
| 6E3274 | 5 SPRING | 1 | |
| 0336043 | 6 SEAL-O-RING | 1 | |
| 6E3272 | 7 SEAT | 1 | |
| 6E6540 | 8 PLUG | 1 | |
| 6E6538 | 9 NUT-ADJUSTMENT (M8X1-THD) | 2 | |
| 6E6537 | 10 SCREW-ADJUSTMENT (M8X1X28-MM) | 2 | |
| 6E6539 | 11 NUT-CAP (M8X1-THD) | 2 | |
| 6E3273 | 12 SEAT | 1 | |
| 6E6536 | 13 PLUG | 1 | |
| 6V8352 | 14 SEAL-O-RING | 1 | |
| 1931036 | 15 SPRING | 1 | |
| 6E3276 | 16 SPRING | 1 | |
| 6E3269 | 17 RETAINER-SPRING | 1 | |
| 1052145 | 18 VALVE-ORIFICE (HYDRAULIC OIL CHECK) | 1 | |
| 5P9262 | 19 SEAL-O-RING | 1 |
