System And Components
582-4923 AIR CONDITIONER GPS/N 7CS1-UP
Group No: 582-4923
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1536932 | 1 GASKET | 1 | |
| 9X8256 | 2 WASHER (6.6X12X2-MM THK) | 2 | |
| 3E5464 | 3 SWITCH AS-THERMOSTAT (HVAC) | 1 | |
| 3S2093 | 4 STRAP-CABLE | 2 | |
| 8C3756 | 5 FILM-IDENTIFICATION (AIR CONDITIONER) | 1 | |
| 8C5682 | 6 TEE | 2 | |
| 1020340 | 7 COVER | 1 | |
| 1175174 | 8 COIL AS-EVAPORATOR | 1 | |
| 1175175 | 9 COIL AS-HEATER | 1 | |
| 1179066 | 10 LATCH AS | 3 | |
| 1188580 | 11 HARNESS AS-HEATER & AIR COND | 1 | |
| 9P2300 | GROMMET | 1 | |
| 6T6505 | HOUSING-RECEPTACLE (BLADE, POSITIVE LOCK) | 6 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 6T6506 | TERMINAL-BLADE (14-GA TO 18-GA) | 6 | |
| 1307245 | 12 PLATE-COVER | 1 | |
| 5811178 | 13 BRACKET | 1 | |
| 1307247 | 14 GASKET | 1 | |
| 1307248 | 15 GASKET | 1 | |
| 1307249 | 16 GASKET | 1 | |
| 1307250 | 17 GASKET | 1 | |
| 1307252 | 18 GASKET | 1 | |
| 1307254 | 19 GASKET | 1 | |
| 1307258 | 20 PLATE AS | 1 | |
| 9V7451 | NUT-WELD (1/4-20-THD) | 2 | |
| 1307277 | 21 PLATE | 1 | |
| 1418896 | 22 STRAP | 1 | |
| 5C9553 | 23 BOLT (M6X1X16-MM) | 2 | |
| 2756706 | 24 MOTOR AS-BLOWER (24-VOLT) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 3945213 | 25 SEAL | 2 | |
| 5443942 | 26 BRACKET | 1 | |
| 5443944 | 27 GASKET | 1 | |
| 5443946 | 28 TUBE | 1 | |
| 5443947 | 29 TUBE | 1 | |
| 5443948 | 30 TUBE | 1 | |
| 5443949 | 31 TUBE | 1 | |
| 5443951 | 32 GASKET | 1 | |
| 5443952 | 33 GASKET | 1 | |
| 5443953 | 34 GASKET | 1 | |
| 5443955 | 35 TUBE | 1 | |
| 5444017 | 36 SCREW (ST4.8X1.6-THD) | 2 | |
| 5444053 | 37 CASE AS | 1 | |
| 5444057 | 38 TUBE | 1 | |
| 5691579 | 39 VALVE AS-WATER | 1 | |
| 4657612 | CLIP | 2 | |
| 4703946 | SEAL-O-RING | 1 | |
| 5461805 | 40 RESISTOR AS | 1 | |
| 0688993 | 41 GROMMET | 1 | |
| 3B4501 | 42 LOCKWASHER | 2 | |
| 3E9865 | 43 LOCKNUT (1/4-20-THD) | 8 | |
| 4M5281 | 44 BOLT (1/4-20X0.75-IN) | 27 | |
| 4M6582 | 45 SEAL-O-RING | 1 | |
| 4P7581 | 46 CLIP (LADDER) | 1 | |
| 5P8167 | 47 BOLT (3/8-16X0.625-IN) | 2 | |
| 7X0499 | 48 NUT-CLINCH (1/4-20-THD) | 19 | |
| 8J1256 | 49 CLIP | 2 | |
| 8L7905 | 50 RIVET-POP | 12 | |
| 8M2771 | 51 CLIP | 2 | |
| 8T0337 | 52 SCREW-MACHINE (M4X0.7X12-MM) | 4 | |
| 8T4121 | 53 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4205 | 54 WASHER-HARD (7.2X14.5X2-MM THK) | 35 | |
| 8T6631 | 55 SCREW-MACHINE (8-32X0.5-IN) | 2 | |
| 9X2185 | 56 SCREW (8-15X0.44-IN) | 4 | |
| 5811221 | 57 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 5P6010 | 58 TUBE (0.2-M) | ||
| 4657612 | 59 CLIP | 1 |
