353-3536 CONTROL GP-TRANSMISSIONS/N 7CS1-UP

Group No: 353-3536

Part Number	Part Name	Qty
3L2540	1 BOLT-SOCKET HEAD (10-24X0.75-IN)	2
5B9318	2 BALL	4
6G0001	3 SHAFT	1
6G4092	4 BUSHING	2
6G4093	5 SPRING	4
6G4134	6 PIN	4
8E1123	7 CLIP	1
8L8413	8 STRAP-CABLE (WHITE)	1
8W0976	9 HOUSING	1
9S8001	10 PLUG (5/16-24-THD)	4
1146658	11 WASHER (6.5X17X1-MM THK)	3
1253357	12 COVER AS	1
1253360	13 COVER AS	1
1253365	14 KNOB (SHIFT LEVER)	1
1267896	15 SENSOR GP-POSITION (TRANSMISSION SHIFT LEVER)	1
1279190	16 LEVER AS (TRANSMISSION CONTROL)	1
6B3057	16A RIVET	2
1279499	17 FILM-INSTRUCTION (TRANSMISSION CONTROL)	1
1279497	FILM-INSTRUCTION (TRANSMISSION CONTROL)	1
1605073	18 HARNESS AS-CONSOLE (TRANSMISSION CONTROL)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
9G3695	PLUG-SEAL	2
9W3086	KEY-POLARIZING	1
9W3087	TERMINAL (CRIMP)	8
9W3089	HOUSING	1
1552260	KIT-CONNECTING PLUG (3-PIN)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	1
1552255	KIT-CONNECTING PLUG (12-PIN)	1
1071984	SOCKET-LAMP	1
1071985	TERMINAL	2
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	17
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	17
1636508	19 LAMP-LED (24-VOLT, WHITE)	1
2109507	20 PLATE AS	1
2504331	21 COVER AS	1
3E6754	23 GROMMET	1
3H2900	24 GROMMET	1
3S2093	25 STRAP-CABLE	2
4J7533	26 SEAL-O-RING	4
5K0906	27 BOLT (5/16-18X0.625-IN)	2
5P1075	28 WASHER-HARD (10.2X22.5X3-MM THK)	8
6V7699	29 WASHER-HARD (5.5X13X1.6-MM THK)	2
6V8185	30 NUT (1/4-20-THD)	3
6V8801	31 NUT (3/8-16-THD)	8
8T4205	32 WASHER-HARD (7.2X14.5X2-MM THK)	3
8T4224	33 WASHER-HARD (8.8X16X2-MM THK)	2
9X2042	34 SCREW-TRUSS HEAD (M6X1X12-MM)	6
