System And Components
2G-1150 HORN GP-AIR -CHASSISS/N 7CS1-UP
Group No: 2G-1150
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D6998 | 1 HORN GP-AIR | 1 | |
| 2H9523 | 2 GROMMET | 1 | |
| 6V3341 | 3 GROMMET | 1 | |
| 5D7132 | 4 CLAMP | 2 | |
| 5D7133 | 5 BRACKET | 1 | |
| 4M5282 | 6 BOLT (1/4-20X1.5-IN) | 2 | |
| 8T4205 | 7 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 6V8185 | 8 NUT (1/4-20-THD) | 2 | |
| 2G0233 | 9 BRACKET | 1 | |
| 6V8918 | 10 BOLT (5/16-18X1.25-IN) | 1 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 6V8189 | 12 NUT (5/16-18-THD) | 1 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 3 | |
| 8T4896 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4S7606 | 15 ELBOW | 1 | |
| 7D6106 | 16 HOSE AS | 1 | |
| 9M8406 | 17 CLIP (LOOP) | 1 | |
| 4S4455 | 18 CLIP | 1 | |
| 6V8801 | 19 NUT (3/8-16-THD) | 1 |
