System And Components
142-5654 LINES GP-AIR CONDITIONER -CABS/N 7CS1-406
Group No: 142-5654
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1098850 | 1 HOSE AS | 1 | |
| 9X7381 | 2 SEAL-O-RING | 2 | |
| 1093587 | 3 HOSE AS | 1 | |
| 5M3062 | 4 BOLT (3/8-16X0.75-IN) | 3 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 1028639 | 6 BRACKET | 1 | |
| 5K8451 | 7 CLIP (LOOP) | 1 | |
| 1097410 | 8 BRACKET AS | 1 | |
| 6V3582 | 9 CLAMP-HOSE | 2 | |
| 6D1641 | 10 CLIP (LOOP) | 1 | |
| 9X7383 | 11 SEAL-O-RING | 2 | |
| 9M8406 | 12 CLIP (LOOP) | 1 | |
| 9X7382 | 13 SEAL-O-RING | 1 | |
| 1515261 | 14 ACCUMULATOR-REFRIGERANT | 1 | |
| 9X7380 | 15 SEAL-O-RING | 2 | |
| 3E3535 | 16 DRYER AS-REFRIGERANT (IN-LINE)(AIR CONDITIONER) | 1 | |
| 8S6109 | 17 CLIP (SLOT) | 1 | |
| 8S6110 | 18 CLIP (TAB) | 1 | |
| 1093586 | 19 HOSE AS | 1 | |
| 1308554 | 20 HOSE AS | 1 | |
| 9X7384 | 21 SEAL-O-RING | 1 | |
| 5P3928 | 22 COUPLING AS-REFRIGERANT (SELF-SEALING) | 1 | |
| 5P4106 | 23 NUT (1-7/16-16-THD) | 1 | |
| 3S8664 | 24 CLIP | 2 | |
| 1036100 | 25 FITTING AS-AIR CONDITIONER (QUICK DISCONNECT) | 1 | |
| 5P4107 | 26 LOCKWASHER | 1 | |
| 1166202 | 27 BOOT | 2 |
