System And Components
142-5656 LINES GP-AIR CONDITIONERS/N 7CS1-UP
Group No: 142-5656
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1305300 | 1 CLIP | 2 | |
| 8T4896 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 3E4054 | 3 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4051 | CAP-SEAL (LOW SIDE CHARGE PORT) | 1 | |
| 3E4057 | VALVE AS (REFRIGERANT, LOW SIDE) | 1 | |
| 9X7385 | 4 SEAL-O-RING | 2 | |
| 3514945 | 5 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4052 | CAP-SEAL (HIGH SIDE CHARGE PORT) | 1 | |
| 3E4058 | VALVE AS (REFRIGERANT, HIGH SIDE) | 1 | |
| 1140067 | 6 PLATE-INSTRUCTION (AIR CONDITIONER LINES) | 1 | |
| 9B7237 | 7 BOLT (3/8-16X1.25-IN) | 2 | |
| 1P6356 | 8 PLATE | 1 | |
| 8T6466 | 9 BOLT (M10X1.5X60-MM) | 1 | |
| 8T7934 | 10 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 6V8801 | 11 NUT (3/8-16-THD) | 2 | |
| 3553148 | 12 SWITCH AS-PRESSURE (HIGH, LOW)(COMPRESSOR, HIGH SIDE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 9X7378 | 13 SEAL-O-RING | 1 | |
| 3S2093 | 14 STRAP-CABLE | 2 | |
| 1893158 | 15 SUPPRESSOR-ARC | 1 |
