System And Components
Assembly
100%

140-8489 PANEL GP-INSTRUMENTS/N 7CS1-227

Group No: 140-8489
Part NumberPart NameQty
14084881 PANEL GP-INSTRUMENT1
12842952 GASKET-PANEL1
9X20463 SCREW-TRUSS HEAD (M6X1X35-MM)6
12568064 MODULE GP-SPEEDOMETER & TACH1
7Y73885 SCREW-BUTTON HEAD (M5X0.8X12-MM)4
16365096 LAMP-LED (24-VOLT, WHITE)2
3E01097 PLUG (ROCKER SWITCH)2
3S20938 STRAP-CABLE1
14488159 PLUG AS-CODE (MONITOR, 769D)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T8737PLUG-SEAL4
144881610 PLUG AS-CODE (MONITOR, 771D)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T8737PLUG-SEAL4
144881711 PLUG AS-CODE (MONITOR, 773D)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
9X3401PIN-CONNECTOR (16-GA TO 18-GA)3
9G3695PLUG-SEAL3
144881812 PLUG AS-CODE (MONITOR, 775D)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T8737PLUG-SEAL4
1028805KIT-RECEPTACLE (6-PIN)1
