System And Components
142-6277 BELT TENSIONER GPS/N 7FR264-UP
Group No: 142-6277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6764 | 1 PLUG-PIPE (1/8-27-THD) | 1 | |
| 1S8687 | 2 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 2M2742 | 3 PLATE-RETAINER | 1 | |
| 2S6150 | 4 COVER-PULLEY | 1 | |
| 2S6151 | 5 GASKET | 1 | |
| 3B4617 | 6 PIN-COTTER | 2 | |
| 3B8485 | 7 ELBOW | 1 | |
| 5M9735 | 8 SEAL-LIP TYPE | 1 | |
| 6B1124 | 9 BALL BEARING | 2 | |
| 6S6308 | 10 PIN | 2 | |
| 6V8188 | 11 NUT (1/2-13-THD) | 1 | |
| 7I1334 | 12 HOSE (23.5CM) | ||
| 8B2327 | 13 RING-RETAINING | 1 | |
| 8N5579 | 14 RETAINER | 1 | |
| 8T4896 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 1357876 | 16 SPRING AS | 1 | |
| 6H6109 | RING-SNAP | 2 | |
| 1426278 | 17 ARM AS (BELT TIGHTENER) | 1 | |
| 4N0955 | DOWEL (35MM LONG) | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 1426280 | 18 PULLEY | 1 | |
| 2S6160 | 19 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 4M6425 | 20 BOLT (5/16-18X1-IN) | 4 | |
| 5M3062 | 21 BOLT (3/8-16X0.75-IN) | 1 | |
| 5S7379 | 22 BOLT (3/8-16X0.875-IN) | 1 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
