System And Components
149-3940 DRIVE GP-FAN -BELTS/N 7FR293-UP
Group No: 149-3940
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S8752 | 1 NUT-FULL (3/8-16-THD) | 6 | |
| 3B8485 | 2 ELBOW | 1 | |
| 5P7979 | 3 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 5P9439 | 4 BALL BEARING | 1 | |
| 6L3616 | 5 CONNECTOR | 1 | |
| 6N1551 | 6 V-BELT SET | 1 | |
| 6N4111 | 7 BRACKET AS | 1 | |
| 5P1198 | 8 TUBE (49CM) | ||
| 4B8756 | NUT-FLARED (7/16-24-THD) | 2 | |
| 7H7107 | 9 SEAL-LIP TYPE | 1 | |
| 7N3629 | 10 ADAPTER-FAN | 1 | |
| 9F4446 | 11 SEAL-O-RING | 1 | |
| 9S7720 | 12 ELBOW-FLARED | 1 | |
| 1426276 | 13 PULLEY-FAN | 1 | |
| 1446674 | 14 HUB-FAN PULLEY | 1 | |
| 1448130 | 15 BEARING AS | 1 | |
| 1493915 | 16 SLEEVE | 1 | |
| 1493921 | 17 SPACER (40.03X53X26.32-MM THK) | 1 | |
| 1493939 | 18 BRACKET AS | 1 | |
| 1S9209 | 18A SHAFT-TIGHTENER (22.29 DIA.) | 1 | |
| 4N0955 | 18B DOWEL (6.38 DIA.) | 1 | |
| 5B5821 | 18C DOWEL (9.37 DIA.) | 1 | |
| 1493925 | 18D SHAFT (39.98 DIA.) | 1 | |
| 1643295 | 19 WASHER-RETAINING | 1 | |
| 0T0573 | 20 BOLT (3/8-16X2.75-IN) | 6 | |
| 7D1728 | 21 CLIP | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4835 | 23 BOLT (1/2-13X2-IN) | 3 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 9B7237 | 25 BOLT (3/8-16X1.25-IN) | 2 |
