System And Components
124-9445 LINES GP-ENGINE OILS/N 99C1500-UP
Group No: 124-9445
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9L6842 | 1 TUBE AS | 1 | |
| 1090078 | 2 SEAL-O-RING | 4 | |
| 0S1591 | 3 BOLT (3/8-16X1.5-IN) | 2 | |
| 0L2070 | 4 BOLT (3/8-16X2.25-IN) | 4 | |
| 6V3830 | 5 SEAL-O-RING | 2 | |
| 1160766 | 6 TUBE AS | 1 | |
| 1W4755 | 7 ADAPTER | 1 | |
| 8N6739 | 8 RING-RETAINING | 1 | |
| 0S1590 | 9 BOLT (3/8-16X2-IN) | 1 | |
| 3B1915 | 10 BOLT (3/8-16X1.375-IN) | 1 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8N6740 | 12 RETAINER | 2 | |
| 1232894 | 13 SUPPORT-SUCTION LINE | 1 | |
| 8N2104 | 14 BELL AS-SUCTION | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 4N0913 | 15 SCREEN-STRAINER | 1 | |
| 4N0914 | 16 CLIP | 1 | |
| 1160765 | 17 TUBE AS-OIL PUMP | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 3 | |
| 8M9024 | 19 WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 0S1571 | 20 BOLT (3/8-16X1.75-IN) | 1 | |
| 1090076 | 21 SEAL-O-RING | 4 | |
| 6N0448 | 22 MANIFOLD | 1 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 7 | |
| 2P3760 | 24 GASKET | 1 | |
| 2P3761 | 25 COVER | 1 | |
| 4N0933 | 26 GASKET | 1 | |
| 1A2029 | 27 BOLT (3/8-16X1.125-IN) | 2 | |
| 2W8438 | 28 TUBE | 1 | |
| 6N0452 | 29 ELBOW-COOLER OUTLET | 1 | |
| 1W4756 | 30 TUBE AS | 1 | |
| 0S1588 | 31 BOLT (3/8-16X1.25-IN) | 2 | |
| 1P1367 | 32 PLUNGER (RELIEF VALVE) | 1 | |
| 4N8150 | 33 SPRING | 1 | |
| 1090072 | 34 SEAL-O-RING | 1 |
