System And Components
193-4734 LINES GP-TURBOCHARGER OILS/N 99C6921-UP
Group No: 193-4734
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N6672 | 1 GASKET | 1 | |
| 4N9431 | 2 ELBOW | 1 | |
| 4P0692 | 3 CLAMP AS | 2 | |
| 1081434 | GROMMET | 1 | |
| 8R3600 | 4 ANGLE | 1 | |
| 1262702 | 5 SEAL-INTEGRAL | 1 | |
| 1986068 | 6 SEAL-INTEGRAL | 1 | |
| 1934735 | 7 TUBE AS | 1 | |
| 1934736 | 8 TUBE AS-DRAIN | 1 | |
| 0L1143 | 9 BOLT (3/8-16X2.5-IN) | 1 | |
| 0S0509 | 10 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 2 | |
| 1142687 | 13 SEAL-O-RING | 1 | |
| 1144427 | 14 SEAL-O-RING | 1 | |
| 3B1915 | 15 BOLT (3/8-16X1.375-IN) | 2 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6V9003 | 17 ELBOW | 1 | |
| 8L2746 | 18 SEAL-O-RING | 1 | |
| 9S8752 | 19 NUT-FULL (3/8-16-THD) | 1 |
