System And Components
122-9199 LINES GP-AIRS/N 7FR264-99999
Group No: 122-9199
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1229198 | 1 ELBOW | 1 | |
| 7N0694 | 2 ELBOW | 1 | |
| 6N4248 | 3 BRACKET | 1 | |
| 6L8562 | 4 STUD-TAPERLOCK (3/8-16X1.77-IN) | 4 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 1B5355 | 6 NUT-FULL (3/8-16-THD) | 12 | |
| 4L6454 | 7 BOLT (3/8-16X1-IN) | 2 | |
| 1315438 | 8 BRACKET AS | 1 | |
| 8T4896 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 4N2493 | 10 ELBOW-EXHAUST | 1 | |
| 1239015 | 11 PIPE AS-AIR TRANSFER | 1 | |
| 0046340 | STUD | 10 | |
| 7M1674 | SCREEN-AIR CLEANER INLET | 1 | |
| 8T8917 | 12 BOLT (1/2-13X1.25-IN) | 4 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9S2592 | 14 HOSE | 1 | |
| 5P3860 | 15 CLAMP-HOSE | 2 | |
| 0S1571 | 16 BOLT (3/8-16X1.75-IN) | 8 | |
| 6N4249 | 17 ELBOW-OUTLET | 1 | |
| 2N2765 | 18 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 4 | |
| 2K4973 | 19 LOCKNUT (3/8-16-THD) | 4 | |
| 9Y8968 | 20 COUPLING-EXHAUST | 1 | |
| 5L8854 | 21 RING-SEALING | 2 | |
| 1A2029 | 22 BOLT (3/8-16X1.125-IN) | 3 | |
| 1229196 | 23 ELBOW | 1 | |
| 9M1869 | 24 PIPE-AIR TRANSFER | 1 | |
| 2M5173 | 25 SEAL-O-RING | 4 | |
| 3B6552 | 26 ELBOW-PIPE | 2 | |
| 8B4884 | 27 ELBOW | 1 | |
| 1W0613 | 28 INDICATOR AS-AIR FILTER CHANGE (SERVICE) | 1 | |
| 1240368 | 29 PIPE | 1 | |
| 1240369 | 30 PIPE | 1 | |
| 6V3970 | 31 GROMMET | 1 |
