System And Components
147-7349 TURBOCHARGER GPS/N 7BJ67001-UP
Group No: 147-7349
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X16-MM) | 2 | |
| 6I0220 | 2 GASKET | 1 | |
| 6I0260 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 6I0563 | 4 NUT (M10X1.5-THD) | 4 | |
| 6I0572 | 5 BOLT (M8X1.25X20-MM) | 2 | |
| 1945390 | 6 GASKET-MANIFOLD | 1 | |
| 1013450 | 10 CLAMP-HOSE | 2 | |
| 8T6703 | 11 CLAMP-HOSE | 2 | |
| 1142590 | 12 CONNECTION | 1 | |
| 1273361 | 13 BOLT (M8X1.25X95-MM) | 7 | |
| 1382043 | 14 WASHER | 1 | |
| 1382061 | 15 ADAPTER | 1 | |
| 1382065 | 16 GASKET | 1 | |
| 1407703 | 17 GASKET-ELBOW | 1 | |
| 1412878 | 18 TUBE | 1 | |
| 1412882 | 19 TUBE | 1 | |
| 1416169 | 20 TUBE AS | 1 | |
| 0676267 | 21 CLIP-TUBE | 1 | |
| 1418584 | 22 BOLT (M8X1.25X50-MM) | 4 | |
| 1434534 | 23 HOSE | 1 | |
| 1446193 | 24 BOLT | 8 | |
| 1478094 | 25 ELBOW | 1 | |
| 2199544 | 26 TURBOCHARGER GP | 1 | |
| 1474577 | 27 BOLT | 4 | |
| 1491136 | 29 WASHER | 3 | |
| 1494236 | 30 STUD (M10X1.5X37-MM) | 4 | |
| 1446195 | 31 MANIFOLD AS-EXHAUST | 1 | |
| 1487132 | 31A FERRULE | 2 | |
| 1606782 | 32 HOSE | 1 | |
| 1622088 | 33 GASKET | 2 | |
| 1644096 | 34 MANIFOLD-INLET | 1 |
