System And Components
144-8807 PUMP GP-REFUELINGS/N 9FS1-137; 2KW1-UP
Group No: 144-8807
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1448808 | 1 SUPPORT AS | 1 | |
| 1205114 | 2 FILM-INSTRUCTION (REFUELING PUMP) | 1 | |
| 1233928 | 3 PUMP & MOTOR GP-FUEL TRANSFER | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1186731 | 4 CAP AS | 1 | |
| 5C0746 | 5 STRAINER GP-FUEL | 1 | |
| 5P0742 | 6 HOSE (350 CM) | ||
| 0065707 | 7 ELBOW-PIPE | 1 | |
| 1026170 | 8 CONNECTOR-HOSE | 1 | |
| 0932068 | 9 GROMMET | 2 | |
| 7I0845 | 10 CONNECTOR | 1 | |
| 4I8443 | 11 VALVE-CHECK | 1 | |
| 0057898 | 12 CONNECTOR-HOSE | 2 | |
| 2S3440 | 13 CLAMP-HOSE | 4 | |
| 1224021 | 14 COVER | 1 | |
| 5C6108 | 15 SWITCH GP-REFUELING (FUEL TANK SHUTOFF) | 1 | |
| 8T4192 | 16 BOLT (M12X1.75X25-MM) | 5 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5P1076 | 18 WASHER-HARD (13.5X30X4-MM THK) | 5 | |
| 8T4908 | 19 BOLT (M8X1.25X25-MM) | 2 | |
| 5P0742 | 20 HOSE (95 CM) | 2 |
