System And Components
162-1571 SUPPORT GP-AIR INLETS/N 6AW1-99999
Group No: 162-1571
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1422624 | 1 GROMMET | 1 | |
| 1630815 | 2 SUPPORT AS | 1 | |
| 7T1099 | 2A LINK | 2 | |
| 8T3490 | 2B NUT-WELD (M10X1.5-THD) | 9 | |
| 8T3597 | 2C NUT-WELD (M12X1.75-THD) | 1 | |
| 8T3612 | 2D NUT-WELD (M8X1.25-THD) | 4 | |
| 1102023 | 2E STUD-WELD (M10X1.5X25-MM) | 1 | |
| 1622506 | 2F TUBE | 1 | |
| 4I6289 | 2G PLATE | 1 | |
| 1630818 | 3 SEAL | 1 | |
| 1687434 | 4 BAFFLE AS | 1 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4189 | 6 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4191 | 7 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4779 | 9 BOLT (M16X2X35-MM) | 4 | |
| 9X8257 | 10 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 2V3726 | 11 BUMPER | 8 |
