System And Components
144-0750 AIR COMPRESSOR GPS/N 6TB9857-UP
Group No: 144-0750
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W9489 | 1 RING-LOCK | 1 | |
| 0S1619 | 2 BOLT (3/8-16X3-IN) | 5 | |
| 0L1352 | 3 BOLT (3/8-16X3.25-IN) | 1 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 0S1615 | 5 BOLT (1/4-20X0.75-IN) | 2 | |
| 3B4504 | 6 LOCKWASHER | 2 | |
| 8T6762 | 7 PLUG-PIPE (1/2-14-THD) | 1 | |
| 1A2029 | 8 BOLT (3/8-16X1.125-IN) | 6 | |
| 3B4506 | 9 LOCKWASHER | 6 | |
| 7N7446 | 10 GASKET | 1 | |
| 7N7442 | 11 GASKET | 1 | |
| 7N7440 | 12 GASKET | 1 | |
| 7N7439 | 13 PLATE-COVER | 1 | |
| 0S1617 | 14 BOLT (5/16-18X0.75-IN) | 6 | |
| 3B4505 | 15 LOCKWASHER | 8 | |
| 8H9789 | 16 BALL BEARING | 2 | |
| 2B2695 | 17 BOLT (5/16-18X0.875-IN) | 2 | |
| 7N7451 | 18 GASKET-UNLOADER | 1 | |
| 9Y2278 | 19 CRANKSHAFT-AIR COMPRESSOR | 1 | |
| 1B8714 | 20 KEY-WOODRUFF | 1 | |
| 7N7450 | 21 COVER-UNLOADER | 1 | |
| 1W9162 | 22 CYLINDER BLOCK | 1 | |
| 7X7732 | 23 PLUG-PIPE | 2 | |
| 4W9479 | 24 MANIFOLD-EXHAUST | 1 | |
| 1S7107 | 25 GASKET | 1 | |
| 7N7447 | 26 HEAD AS-COMPRESSOR | 1 | |
| 5L5502 | FITTING | 1 | |
| 1245572 | VALVE AS-RELIEF (AIR COMPRESSOR) | 1 | |
| 7N7448 | 27 GASKET | 1 | |
| 7N7441 | 28 COVER-AIR COMPRESSOR | 1 | |
| 0344160 | 29 BOLT-LOCKING (5/16-18X1-IN) | 4 | |
| 4W6681 | 30 CRANKCASE GP-AIR COMPRESSOR | 1 | |
| 8T6764 | 31 PLUG-PIPE (1/8-27-THD) | 1 | |
| 1389057 | 32 VALVE (PRESSURE RELIEF) | 1 | |
| 1440503 | KIT-PISTON & RING (STANDARD)(AIR COMPRESSOR) | 1 | |
| 1382887 | KIT-ROD & BEARING (AIR COMPRESSOR) | 1 | |
| 7N7435 | KIT-AIR COMPRESSOR (MAJOR REPAIR) | 1 | |
| 1440502 | KIT-PISTON RING (STANDARD)(AIR COMPRESSOR) | 1 |
