System And Components
1N-2992 AIR COMPRESSOR GPS/N 6TB9857-UP
Group No: 1N-2992
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N2994 | 1 CRANKCASE GP-AIR COMPRESSOR | 1 | |
| 1S9867 | 2 BUSHING | 1 | |
| 0S1615 | 3 BOLT (1/4-20X0.75-IN) | 6 | |
| 3B4504 | LOCKWASHER | 6 | |
| 3B4505 | 4 LOCKWASHER | 6 | |
| 9M0379 | 5 BOLT | 10 | |
| 2B0858 | 6 PLUG-PIPE | 1 | |
| 2W5133 | 7 CYLINDER HEAD AS | 1 | |
| 2H3755 | 8 BOLT (5/16-18X0.43-IN) | 2 | |
| 2A0954 | 9 COVER-OUTLET | 1 | |
| 1S7107 | GASKET | 1 | |
| 2S3079 | 10 COVER-AIR COMPENSATOR | 1 | |
| 3H5175 | GASKET | 1 | |
| 8S4645 | 11 LOCK | 4 | |
| 1N2993 | 12 CRANKSHAFT-AIR COMPRESSOR | 1 | |
| 9N2855 | 13 GASKET-CYLINDER HEAD | 1 | |
| 9N5449 | 14 CYLINDER BLOCK AS | 1 | |
| 3H7311 | 15 GASKET-CYLINDER BLOCK | 1 | |
| 2S4013 | 16 COVER AS-END | 1 | |
| 2S4245 | BUSHING | 1 | |
| 1B8714 | 17 KEY-WOODRUFF | 1 | |
| 9L1517 | 18 WASHER-THRUST | 1 | |
| 0S1617 | 19 BOLT (5/16-18X0.75-IN) | 4 | |
| 2H3931 | 20 SEAL-O-RING | 1 | |
| 5M6213 | 21 PLUG-PIPE (1/4-18-THD) | 1 | |
| 3J5390 | 22 PLUG (3/8-18-THD) | 4 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 6 | |
| 3B4506 | LOCKWASHER | 6 | |
| 9L1518 | 24 WASHER-THRUST | 1 | |
| 7C4944 | 25 PISTON AS-COMPRESSOR | 2 | |
| 1W2803 | PLUG | 2 | |
| 8N5916 | 26 ROD AS-CONNECTING | 2 | |
| 4N3994 | BEARING | 1 | |
| 9M5181 | BOLT | 2 | |
| 3J5389 | 27 PLUG (EXTERNAL) | 1 | |
| 7C4943 | KIT-PISTON RING (AIR COMPRESSOR) | 1 | |
| 2W6044 | KIT-AIR COMPRESSOR | 1 | |
| 6I1220 | KIT-UNLOADER (AIR COMPRESSOR) | 1 |
