System And Components
7W-4020 AIR COMPRESSOR GPS/N 6TB9857-UP
Group No: 7W-4020
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C6165 | 1 CYLINDER HEAD AS | 1 | |
| 3F4987 | 2 SPRING-VALVE | 4 | |
| 3H5181 | 3 VALVE | 4 | |
| 9M0394 | 4 SEAT-VALVE | 4 | |
| 1245572 | 5 VALVE AS-RELIEF (AIR COMPRESSOR) | 1 | |
| 9M0379 | 6 BOLT | 18 | |
| 0L1351 | 7 BOLT (3/8-16X0.875-IN) | 10 | |
| 3B4506 | 8 LOCKWASHER | 20 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 10 | |
| 2B2695 | 10 BOLT (5/16-18X0.875-IN) | 4 | |
| 3B4505 | 11 LOCKWASHER | 4 | |
| 7F2742 | 12 BALL BEARING | 1 | |
| 7C6177 | 13 WASHER-THRUST | 1 | |
| 3J5389 | 14 PLUG (EXTERNAL) | 3 | |
| 7C6172 | 15 GASKET-CYLINDER HEAD | 1 | |
| 7C6173 | 16 GASKET-CYLINDER BLOCK | 1 | |
| 7C6174 | 17 GASKET | 1 | |
| 7C6175 | 18 COVER-REAR | 1 | |
| 9M4791 | 19 GASKET-END COVER | 1 | |
| 3J5390 | 20 PLUG (3/8-18-THD) | 4 | |
| 8B8817 | 21 PLUG | 1 | |
| 4B4845 | 22 PLUG | 2 | |
| 7C4944 | 23 PISTON AS-COMPRESSOR | 4 | |
| 1W2803 | 24 PLUG | 2 | |
| 8N5916 | 25 ROD AS-CONNECTING | 4 | |
| 4N3994 | 26 BEARING | 1 | |
| 9M5181 | 27 BOLT | 2 | |
| 1B8714 | 28 KEY-WOODRUFF | 1 | |
| 7C6164 | KIT-AIR COMPRESSOR (MAJOR REPAIR) | 1 | |
| 7C4943 | KIT-PISTON RING (AIR COMPRESSOR) | 2 | |
| 6I1220 | KIT-UNLOADER (AIR COMPRESSOR) | 1 |
