System And Components
8N-9267 CYLINDER BLOCK GPS/N 6TB17608-20164
Group No: 8N-9267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1515929 | 1 JET AS-PISTON COOLING | 6 | |
| 8T6757 | 2 PLUG-PIPE | 3 | |
| 7W6534 | 3 PLUG-PIPE | 1 | |
| 2W6000 | 4 LINER-CYLINDER BLOCK | 6 | |
| 8T6763 | 5 PLUG-PIPE (1/4-18-THD) | 3 | |
| 1S9540 | 6 DOWEL | 2 | |
| 3S5496 | 7 SEAL-O-RING | 2 | |
| 7W6492 | 8 PLUG-PIPE (1/2-14-THD) | 1 | |
| 0307571 | 9 BOLT (3/8-16X1-IN) | 4 | |
| 4W8585 | 10 COVER | 1 | |
| 7W6081 | 11 GASKET | 1 | |
| 9X7378 | 12 SEAL-O-RING | 1 | |
| 4N0683 | 13 DOWEL | 4 | |
| 4N1650 | 14 DOWEL | 2 | |
| 6I2981 | 15 PLATE-BLOCK | 1 | |
| 6I4024 | 16 GASKET-PLATE | 1 | |
| 8S9094 | 17 PLUG-ORIFICE | 1 | |
| 9S4190 | 18 PLUG-O-RING (7/8-14-THD) | 1 | |
| 1144427 | 19 SEAL-O-RING | 1 | |
| 7X7732 | 20 PLUG-PIPE | 6 | |
| 1515925 | 21 BOLT (7/16-14-THD) | 6 | |
| 8T6764 | 24 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S8009 | 25 PLUG-O-RING | 1 | |
| 1195155 | 26 SEAL-O-RING | 1 | |
| 1102220 | 27 SEAL-LINER | 18 | |
| 3P1323 | 28 BOLT-BEARING CAP (7/8-14X7.75-IN) | 14 | |
| 9H1031 | 29 WASHER-HARD (24X41.5X6-MM THK) | 14 | |
| 4N5857 | 30 CAP-CRANKSHAFT BEARING | 7 | |
| 9L5854 | 31 BAND-FILLER (130.2-MM ID) | 6 | |
| 4W4588 | 32 SLEEVE-LIFTER BORE | ||
| 9S4190 | 33 PLUG-O-RING (7/8-14-THD) | 1 | |
| 1144427 | 34 SEAL-O-RING | 1 | |
| 1007399 | 35 PLUG | 2 | |
| 3E6747 | 36 SEAL-O-RING | 2 | |
| 9S4182 | 37 PLUG (7/16-20-THD) | 1 | |
| 4W6061 | SLEEVE | ||
| 5N0093 | INSERT-LINER SEAT (2.71-MM THK) | ||
| 6I4365 | INSERT-LINER SEAT (2.66-MM THK) | ||
| 6I4366 | INSERT-LINER SEAT (2.76-MM THK) | ||
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | ||
| 6I4363 | INSERT-LINER SEAT (1.555-MM THK) | ||
| 6I4364 | INSERT-LINER SEAT (1.655-MM THK) | ||
| 9Y3368 | INSERT-LINER SEAT (0.822-MM THK) | ||
| 6I4361 | INSERT-LINER SEAT (0.772-MM THK) | ||
| 6I4362 | INSERT-LINER SEAT (0.872-MM THK) |
