System And Components
7N-8838 DRIVE GP-FANS/N 6TB9857-UP
Group No: 7N-8838
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4566 | 1 BOLT (1/2-13X3.5-IN) | 2 | |
| 1F7960 | 2 WASHER (13.5X32X6-MM THK) | 4 | |
| 4N2372 | 3 ADAPTER-BRACKET | 1 | |
| 8L5213 | 4 BOLT (3/8-16X4-IN) | 1 | |
| 1D4719 | 5 NUT-FULL (1/2-13-THD) | 2 | |
| 5S2106 | 6 SEAL-LIP TYPE | 1 | |
| 8H9789 | 7 BALL BEARING | 1 | |
| 4N6289 | 8 PULLEY-FAN DRIVE (3-GROOVE) | 1 | |
| 7N8827 | 9 HUB | 1 | |
| 5S7264 | 10 WASHER-RETAINING (0.219-IN THK)(42.93MM) | 1 | |
| 7N2900 | RETAINER (47.63MM) | 1 | |
| 1H5403 | 11 BOLT (5/16-24X2-IN)(50.8MM) | 2 | |
| 5P7979 | BOLT-LOCKING (5/16-24X2.25-IN)(57.15MM) | 2 | |
| 4N2370 | 12 ADAPTER-FAN | 1 | |
| 1B5174 | 13 PLUG-PIPE | 1 | |
| 3L1425 | 14 BALL BEARING | 1 | |
| 9F4446 | 15 SEAL-O-RING | 1 | |
| 4N8217 | 16 V-BELT SET (INCLUDES 2-BELTS)(FAN DRIVE) | 1 | |
| 0L2070 | 17 BOLT (3/8-16X2.25-IN) | 6 | |
| 2P2243 | 18 SPACER (1.438X1.75X1.722-IN THK) | 1 | |
| 6N7688 | 19 BRACKET AS-FAN | 1 | |
| 4N0684 | 20 DOWEL | 1 | |
| 5S9062 | 21 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 4B4550 | 22 FITTING-PRESSURE RELIEF (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 2P9084 | 23 STUD-TAPERLOCK (1/2-13X0.83-IN, 1/2-13X0.98-IN) | 2 | |
| 1A2029 | 24 BOLT (3/8-16X1.125-IN) | 2 | |
| 9N5120 | 25 BRACKET | 1 | |
| 2D4867 | 26 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 |
