System And Components
7N-8978 DRIVE GP-FANS/N 6TB9857-UP
Group No: 7N-8978
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7D1649 | 1 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 1F7958 | 2 NUT-FULL (1/2-13-THD) | 2 | |
| 2P9084 | 3 STUD-TAPERLOCK (1/2-13X0.83-IN, 1/2-13X0.98-IN) | 2 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 2 | |
| 9N5120 | 5 BRACKET | 1 | |
| 4N2372 | 6 ADAPTER-BRACKET | 1 | |
| 5R1771 | 7 BOLT (3/8-16X5.5-IN) | 1 | |
| 1D4566 | 8 BOLT (1/2-13X3.5-IN) | 2 | |
| 5S9062 | 9 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 0L2070 | 10 BOLT (3/8-16X2.25-IN) | 6 | |
| 7N8828 | 11 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 7N8827 | 12 HUB | 1 | |
| 8N5305 | 13 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 4N3123 | 14 ADAPTER-FAN | 1 | |
| 2D4867 | 15 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 5P7979 | 16 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 7N2900 | 17 RETAINER | 1 | |
| 3L1425 | 18 BALL BEARING | 1 | |
| 9F4446 | 19 SEAL-O-RING | 1 | |
| 8H9789 | 20 BALL BEARING | 1 | |
| 5S2106 | 21 SEAL-LIP TYPE | 1 | |
| 6N6656 | 22 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE) | 1 | |
| 6N7688 | 23 BRACKET AS-FAN | 1 | |
| 4N0684 | 23A DOWEL | 1 | |
| 1P9946 | 23B SHAFT-FAN | 1 | |
| 6U1989 | 24 VALVE-RELIEF (FAN DRIVE) | 1 |
