System And Components
6I-1820 LINES GP-AIR COMPRESSORS/N 6TB9857-UP
Group No: 6I-1820
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L6557 | 1 CONNECTOR | 1 | |
| 4P2446 | 2 HOSE AS | 1 | |
| 2N1287 | 3 ELBOW-FLARED | 1 | |
| 3E7430 | 4 PLUG-PIPE (3/4-14-THD) | 1 | |
| 3B7744 | 5 FITTING | 1 | |
| 5B8979 | 6 TEE-PIPE | 1 | |
| 8T6762 | 7 PLUG-PIPE (1/2-14-THD) | 2 | |
| 4N4935 | 8 HOSE AS | 1 | |
| 7C0367 | 9 MANIFOLD | 1 | |
| 8M7065 | 10 GASKET (AIR INLET) | 3 | |
| 2B2695 | 11 BOLT (5/16-18X0.875-IN) | 4 | |
| 9M1974 | 12 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 2N1288 | 13 ELBOW | 1 | |
| 1K6937 | 14 ELBOW-PIPE | 1 | |
| 7W9827 | 15 ADAPTER | 1 | |
| 7W9812 | 16 HOSE AS | 1 | |
| 4N8470 | 17 HOSE AS | 1 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 4 | |
| 0308307 | 19 CONNECTOR | 1 | |
| 7C0307 | 20 GASKET | 1 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6D4636 | 22 CLIP (LOOP) | 1 | |
| 6G9869 | 23 HOSE AS | 1 | |
| 2F4967 | 24 SPACER (10.5X19X5.512-MM THK) | 1 | |
| 9L5254 | 25 ELBOW | 1 | |
| 0321269 | 26 ELBOW | 1 | |
| 0S1594 | 27 BOLT (3/8-16X1-IN) | 3 | |
| 0017043 | 28 ELBOW | 1 | |
| 3B7747 | 29 NIPPLE-PIPE | 1 | |
| 6I1819 | 30 COVER | 1 | |
| 0192082 | 31 FITTING (PIPE) | 1 | |
| 7W9834 | 32 VALVE-REGULATOR | 1 | |
| 1B9575 | 33 BOLT (5/16-18X1.56-IN) | 2 | |
| 5S0003 | 34 NUT (5/16-18-THD) | 2 | |
| 1S9799 | 35 SEAL-O-RING | 1 | |
| 6N7854 | 36 COVER | 1 | |
| 7X7732 | 37 PLUG-PIPE | 1 | |
| 7L7262 | 38 ELBOW-FLARED | 1 | |
| 4P6791 | 39 PLATE AS-ENGINE GROUND | 1 | |
| 2N8630 | 40 GASKET | 1 | |
| 4L6454 | 41 BOLT (3/8-16X1-IN) | 2 | |
| 8T4896 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
