System And Components
165-0577 AFTERCOOLER GP-WATERS/N 6TB18461-UP
Group No: 165-0577
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S8752 | 1 NUT-FULL (3/8-16-THD) | 4 | |
| 8N8100 | 2 ADAPTER | 1 | |
| 7W0688 | 3 GASKET | 2 | |
| 4W4775 | 4 ADAPTER | 2 | |
| 8N8099 | 5 COVER | 1 | |
| 1535484 | 6 GASKET | 2 | |
| 1W0512 | 7 COVER | 1 | |
| 5M2894 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 4N4193 | 9 ADAPTER | 2 | |
| 2N8204 | 10 GASKET | 6 | |
| 6L9589 | 11 GASKET | 2 | |
| 5P8068 | 12 SEAL-O-RING | 2 | |
| 1W4879 | 13 CORE AS-AFTERCOOLER | 1 | |
| 8N8098 | 14 HOUSING | 1 | |
| 8T6764 | 15 PLUG-PIPE (1/8-27-THD) | 4 | |
| 7W6492 | 16 PLUG-PIPE (1/2-14-THD) | 1 | |
| 0310219 | 17 BOLT-LOCKING (3/8-16X1.75-IN) | 11 | |
| 5D9844 | 18 BOLT-LOCKING (3/8-16X2-IN) | 1 | |
| 1B9575 | 19 BOLT (5/16-18X1.56-IN) | 12 | |
| 9M1974 | 20 WASHER-HARD (8.8X16X2-MM THK) | 26 | |
| 8T6765 | 21 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P7204 | 22 SEAL-O-RING | 2 | |
| 2B2694 | 23 BOLT (5/16-18X2-IN) | 22 | |
| 8T6762 | 24 PLUG-PIPE (1/2-14-THD) | 1 | |
| 3E7430 | 25 PLUG-PIPE (3/4-14-THD) | 1 | |
| 9F8999 | 26 BOLT (3/8-16X7-IN) | 4 |
