Assembly
100%

4N-4077 AFTERCOOLER GP-WATERS/N 6TB9857-UP

Group No: 4N-4077
Part NumberPart NameQty
15354841 GASKET2
1B95752 BOLT (5/16-18X1.56-IN)33
9M19743 WASHER-HARD (8.8X16X2-MM THK)25
4N90274 COVER1
4N41935 ADAPTER2
5D98446 BOLT-LOCKING (3/8-16X2-IN)1
4W47757 ADAPTER2
6L95898 GASKET2
10900789 SEAL-O-RING (33.47MM ID)2
5P720410 SEAL-O-RING (34.29MM ID)2
1W699011 CORE AS-AFTERCOOLER1
2N820412 GASKET6
8N809813 HOUSING1
8T676414 PLUG-PIPE (1/8-27-THD)(1/8-27 NPTF THD)3
8T676215 PLUG-PIPE (1/2-14-THD)2
031021916 BOLT-LOCKING (3/8-16X1.75-IN)11
5M289417 WASHER-HARD (10.2X18.5X2.5-MM THK)12
3E743018 PLUG-PIPE (3/4-14-THD)1
8T676419 PLUG-PIPE (1/8-27-THD)(1/8-27 NPTF THD)1
