System And Components
3N-4582 SHUTOFF GP-AIRS/N 6TB9857-UP
Group No: 3N-4582
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4L8337 | 1 SEAL-O-RING | 2 | |
| 4N2888 | 2 PIPE-AIR TRANSFER | 1 | |
| 4P8021 | 3 VALVE AS (AIR SHUTOFF) | 1 | |
| 5H1190 | 4 SEAL-LIP TYPE | 1 | |
| 1082858 | 5 SPRING | 1 | |
| 4N2883 | 6 SHAFT-SHUTOFF | 1 | |
| 5N3160 | 7 STUD (1/4-20X2-IN) | 1 | |
| 6V8185 | 8 NUT (1/4-20-THD) | 1 | |
| 8T4205 | 9 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5N5662 | 10 LATCH | 1 | |
| 5N1703 | 11 SPACER (6.8X21X9.52-MM THK) | 1 | |
| 5N5131 | 12 BLOCK AS | 1 | |
| 5H5744 | 13 BUSHING-TERMINAL | 1 | |
| 1W9070 | 14 DIODE AS | 1 | |
| 4N3889 | 15 SOLENOID-SHUTOFF (12-VOLT) | 1 | |
| 1H3337 | 16 BOLT (1/4-20X0.875-IN) | 2 | |
| 3N7848 | 17 SPRING | 1 | |
| 8B8679 | 18 SPACER (0.406X0.75X0.44-IN THK) | 2 | |
| 5N5129 | 19 SHAFT | 1 | |
| 5N5664 | 20 BRACKET AS | 1 | |
| 0S1594 | 21 BOLT (3/8-16X1-IN) | 2 | |
| 5S1188 | 22 SEAL-O-RING | 2 | |
| 1C0569 | 23 BOLT (5/16-18X0.5-IN) | 2 | |
| 9S5282 | WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5N2829 | 25 BUSHING-TERMINAL | 1 | |
| 2L3605 | PIN-SPRING | 1 | |
| 5N3852 | 26 BEARING | 2 | |
| 6V8801 | 27 NUT (3/8-16-THD) | 2 |
