System And Components
3N-7549 SHUTOFF GP-AIRS/N 6TB9857-UP
Group No: 3N-7549
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N8630 | 1 GASKET | 1 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3N7547 | 3 PIPE-AIR TRANSFER | 1 | |
| 5N5129 | 4 SHAFT | 1 | |
| 1W9070 | 5 DIODE AS | 1 | |
| 4N3890 | 6 SOLENOID AS (24-VOLT)(AIR SHUTOFF) | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 4F7957 | 7 BOLT (1/4-20X0.875-IN) | 2 | |
| 5P0537 | 8 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5N5666 | 9 BRACKET AS | 1 | |
| 5N5131 | 10 BLOCK AS | 1 | |
| 5H5744 | 11 BUSHING-TERMINAL | 1 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 2 | |
| 5N2829 | 13 BUSHING-TERMINAL | 1 | |
| 2L3605 | PIN-SPRING | 1 | |
| 5N3852 | 14 BEARING | 2 | |
| 5S1188 | 15 SEAL-O-RING (88.26MM ID) | 2 | |
| 7L4984 | 16 STUD-TAPERLOCK (5/16-18X3.5-IN) | 1 | |
| 4N2882 | 17 VALVE AS (AIR SHUTOFF) | 1 | |
| 5H1190 | 18 SEAL-LIP TYPE | 1 | |
| 3N9106 | 19 SPRING | 1 | |
| 9F6580 | 20 BOLT (1/4-20X1.125-IN) | 1 | |
| 4N2883 | 21 SHAFT-SHUTOFF | 1 | |
| 5N5668 | 22 LATCH | 1 | |
| 9S5282 | 23 WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 1C0569 | 24 BOLT (5/16-18X0.5-IN) | 2 | |
| 5N1703 | 25 SPACER (6.8X21X9.52-MM THK) | 1 | |
| 3N7848 | 26 SPRING | 1 |
