System And Components
5N-2060 SHUTOFF GP-AIRS/N 6TB9857-UP
Group No: 5N-2060
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N4159 | 1 GASKET | 1 | |
| 4P8021 | 2 VALVE AS | 1 | |
| 4S6517 | 3 PLUG-CUP | 1 | |
| 5N2830 | 4 SHAFT AS | 1 | |
| 2L3605 | PIN-SPRING | 1 | |
| 4N2883 | SHAFT-SHUTOFF | 1 | |
| 5N2829 | BUSHING-TERMINAL | 1 | |
| 5N3160 | 5 STUD (1/4-20X2-IN) | 1 | |
| 5N3852 | 6 BEARING | 2 | |
| 5N5662 | 7 LATCH | 1 | |
| 1354649 | 8 SPRING | 1 | |
| 4189837 | 9 PIPE-OUTLET | 1 | |
| 1305694 | 10 SEAL-O-RING | 2 | |
| 3134327 | 11 SPACER (8.5X16X8-MM THK) | 2 | |
| 3135637 | 12 BOLT (5/16-18X0.75-IN) | 2 | |
| 4L8337 | 13 SEAL-O-RING | 2 | |
| 5H1190 | 14 SEAL-LIP TYPE | 1 | |
| 6V8185 | 15 NUT (1/4-20-THD) | 1 | |
| 8T4205 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T6765 | 17 PLUG-PIPE (1/4-18-THD) | 1 |
