System And Components
7N-0011 TURBOCHARGER GPS/N 6TB9857-UP
Group No: 7N-0011
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N7158 | 1 HOUSING AS-COMPRESSOR | 1 | |
| 9L6913 | 2 HOUSING (TURBINE) | 1 | |
| 3S5129 | 3 CLAMP AS (COMPRESSOR) | 1 | |
| 3S5126 | 5 BOLT-HIGH TEMPERATURE (3/8-16X0.625-IN) | 6 | |
| 3S5127 | PLATE-CLAMP | 3 | |
| 3S5128 | PLATE-LOCK | 3 | |
| 9L6239 | 7 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 9L6243 | HOUSING AS | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 9N2041 | 7A KIT-BEARING | 1 | |
| 3S4488 | 8 SCREW-MACHINE | 3 | |
| 3S4487 | PLATE-LOCK | 3 | |
| 3S4484 | 9 LOCKNUT-TURBOCHARGER (5/16-24-THD) | 1 | |
| 9L6242 | 10 WHEEL-COMPRESSOR | 1 | |
| 8S8043 | 11 SPACER-THRUST | 1 | |
| 9M8919 | 12 RING-SEAL | 2 | |
| 5P5756 | 13 SEAL-O-RING | 1 | |
| 3S5135 | 14 SEAL-O-RING | 1 | |
| 8S5169 | 15 PLATE AS-THRUST | 1 | |
| 8S8042 | 16 COLLAR-THRUST | 1 | |
| 6N5004 | 17 BEARING-THRUST | 1 | |
| 7N3760 | 18 SHROUD | 1 | |
| 9M8915 | 19 RING-RETAINING | 3 | |
| 9L6244 | 20 WHEEL AS | 1 | |
| 7N3759 | 21 RING-PISTON | 1 | |
| 7N3193 | 24 KIT-BEARING (0.13-MM OS,0.13-MM US)(TURBOCHARGER) | 1 | |
| 7N3194 | KIT-BEARING (0.25-MM OS, 0.25-MM US)(TURBOCHARGER) | 1 | |
| 2W0719 | KIT-CARTRIDGE (TURBOCHARGER) | 1 |
