4W-7140 CLUTCH GPS/N 38S16484-UP

Group No: 4W-7140

Part Number	Part Name	Qty
9X8873	1 BOLT (1/2-13X2.25-IN)	1
1F7958	NUT-FULL (1/2-13-THD)	1
2W3733	2 FITTING-HYDRAULIC (CLUTCH)	2
9F2247	3 PLUG-PIPE (1/8-27-THD)	1
6F6582	4 SHAFT-OPERATING	1
6L5202	KEY-WOODRUFF	2
9X8882	5 BOLT (5/8-11X2.5-IN)	8
3N8427	6 CARRIER AS-BEARING	1
3B8489	7 FITTING-GREASE (1/8-27 PTF)(CLUTCH)	1
9S1354	NUT (5/8-18-THD)	1
6F0253	LOCKWASHER	1
9B2515	8 FITTING-HYDRAULIC (CLUTCH)	1
1083561	9 PLATE-INSTRUCTION (POWER TAKE-OFF)	1
1L6931	10 SCREW AS-MACHINE (1/4-20X0.5-IN)	2
3K6905	11 VALVE-BREATHER (TRANSMISSION)	1
3N8426	12 HOUSING-CLUTCH	1
4W2654	13 LEVER-HAND CONTROL	1
2W3648	14 SHAFT-CLUTCH	1
2L6010	15 PLUG-PIPE	2
0S1594	16 BOLT (3/8-16X1-IN)	6
5L3560	PLATE-LOCK	3
5L3617	17 SEAL-RUBBER	1
6F6581	18 YOKE-CLUTCH	1
1A1460	19 BOLT (1/2-13X2-IN)	2
3N8429	20 SLEEVE-SLIDING	1
2L7161	21 RING	1
3N8124	22 SPRING	1
3N8306	LOCK PIN	1
5N6136	23 PLATE-DRIVE	2
2L7162	24 PLATE	1
5N8132	25 RING-DRIVE	1
2L7152	26 LOCK	1
2L7151	27 NUT	1
7F2167	28 KEY	1
3N8434	29 PLATE-HUB & BACK	1
3N8430	30 PLATE-FLOATING	1
2L4437	31 LEVER	4
6L3973	32 PIN	4
6L3963	PIN-COTTER	4
2L4441	WASHER	8
6L3971	33 PIN	8
6L3962	PIN-COTTER	8
4B4760	34 LINK	8
8L5096	35 HOSE AS	1
6F6580	36 COLLAR AS-CONE	1
0L1558	BOLT (1/2-20X3.25-IN)	2
2K0564	LOCKNUT (1/2-20-THD)	2
4B4723	SHIM (1.52MM THK)	2
5L3613	37 RETAINER-BEARING	1
5L3556	38 SHIM (0.0200-IN THK)(.14MM THK)	1
5L3557	SHIM (0.010-IN THK)(.20MM THK)	1
5L3558	SHIM (0.007-IN THK)(.28MM THK)	1
5L3559	SHIM (0.005-IN THK)(.56MM THK)	1
5L1545	39 CUP-BEARING	2
7L6551	40 CONE-BEARING	2
2W4904	41 RING-SEAL	2
1083560	42 PLATE-WARNING (POWER TAKE-OFF)	1
