System And Components
491-0230 DRIVE GP-FANS/N 38S16484-UP
Group No: 491-0230
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N2538 | 1 BRACKET-FAN ADJUSTMENT | 1 | |
| 4N6288 | 2 PULLEY-FAN DRIVE (3-GROOVE) | 1 | |
| 6N2547 | 3 ADAPTER-FAN BRACKET | 1 | |
| 6N9158 | 4 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 7E4808 | 5 PLATE | 1 | |
| 3330773 | 6 SPACER-SPECIAL (39X47.5X18-MM THK) | 1 | |
| 3332408 | 7 BALL BEARING | 2 | |
| 4206942 | 8 SPACER (40.4X49X5-MM THK) | 1 | |
| 4446555 | 9 BRACKET AS | 1 | |
| 4N0684 | DOWEL | 1 | |
| 4910682 | 10 HUB | 1 | |
| 4910683 | 11 SPACER | 1 | |
| 5160005 | 12 ADAPTER-FAN | 1 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 2 | |
| 1F7958 | 14 NUT-FULL (1/2-13-THD) | 4 | |
| 2M2488 | 15 STUD-TAPERLOCK (3/8-16X3.59-IN) | 6 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6H3956 | 17 PIN | 1 | |
| 7D1649 | 18 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 8L5213 | 19 BOLT (3/8-16X4-IN) | 1 | |
| 9L0553 | 20 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 7 | |
| 0L1329 | 22 BOLT (1/2-13X3-IN) | 1 |
