System And Components
294-5799 LINES GP-AIR COMPRESSORS/N 38S16484-UP
Group No: 294-5799
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0321269 | 1 ELBOW | 2 | |
| 6N7854 | 2 COVER | 1 | |
| 0317476 | 3 HOSE AS | 1 | |
| 0308195 | 4 CONNECTOR | 1 | |
| 1144427 | 5 SEAL-O-RING | 1 | |
| 7K9197 | 6 ELBOW | 1 | |
| 8M2773 | 7 CLIP (LOOP) | 2 | |
| 1B2790 | 8 BOLT (5/16-18X1.375-IN) | 2 | |
| 9M1974 | 9 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8R7781 | 10 HOSE AS | 1 | |
| 8J8197 | 11 CLIP | 1 | |
| 1A0168 | 12 BOLT (1/2-13X7.5-IN) | 1 | |
| 2M0849 | 13 WASHER-HARD (13.5X25.5X5-MM THK) | 2 | |
| 1F7958 | 14 NUT-FULL (1/2-13-THD) | 1 | |
| 9L5254 | 15 ELBOW | 2 | |
| 6L5652 | 16 ADAPTER | 2 | |
| 9L5125 | 17 ELBOW | 1 | |
| 6N8659 | 18 HOSE AS | 1 | |
| 0616802 | 19 HOSE AS | 1 | |
| 0017043 | 20 ELBOW | 1 | |
| 0616806 | 21 HOSE AS | 1 | |
| 8B2664 | 22 BUSHING-REDUCER | 1 | |
| 2N3378 | 23 ELBOW-FLARED | 3 | |
| 4K0367 | 24 NUT-FULL (5/8-11-THD) | 1 | |
| 0S1592 | 25 BOLT (5/8-11X1.25-IN) | 1 | |
| 2M0287 | 26 CLIP-WIRE | 1 | |
| 1325789 | 27 CLIP (LADDER) | 2 | |
| 3S2093 | 28 STRAP-CABLE | 4 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 7C0307 | 30 GASKET | 1 |
