System And Components
8N-3036 LINES GP-ENGINE OIL -LH MOUNTED FILTERS/N 38S16484-UP
Group No: 8N-3036
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P3760 | 1 GASKET | 1 | |
| 2P3761 | 2 COVER | 1 | |
| 4N8150 | 3 SPRING | 1 | |
| 6N0448 | 4 MANIFOLD | 1 | |
| 6N0624 | 5 TUBE AS-OUTLET | 1 | |
| 6N4755 | 6 TUBE AS-OUTLET | 1 | |
| 1P1367 | 7 PLUNGER (RELIEF VALVE) | 1 | |
| 9N0324 | 8 ELBOW-COOLER OUTLET | 1 | |
| 9N0326 | 9 ELBOW | 1 | |
| 1981517 | 10 GASKET | 2 | |
| 1983175 | 11 COVER | 1 | |
| 0L1352 | 12 BOLT (3/8-16X3.25-IN) | 1 | |
| 0L2070 | 13 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1590 | 14 BOLT (3/8-16X2-IN) | 1 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 13 | |
| 1135304 | 16 SEAL-O-RING | 3 | |
| 2S9750 | 17 COVER | 1 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P4268 | 19 SEAL-O-RING | 1 | |
| 5P5846 | 20 SEAL-O-RING | 1 | |
| 5P8068 | 21 SEAL-O-RING | 4 |
