System And Components
4W-1239 CARTRIDGE GP-TURBOCHARGERS/N 38S16484-UP
Group No: 4W-1239
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3562 | 1 WHEEL-COMPRESSOR | 1 | |
| 1N3712 | 2 BEARING-THRUST | 1 | |
| 1272378 | 3 SEAL-RING | 1 | |
| 1N3365 | 4 COLLAR-THRUST | 1 | |
| 9M8919 | 5 RING-SEAL | 2 | |
| 5P7234 | 6 RING-RETAINING | 3 | |
| 9B7237 | 7 BOLT (3/8-16X1.25-IN) | 4 | |
| 1N3383 | 8 PLATE AS-BACKING | 1 | |
| 7W0130 | BEARING-THRUST | 1 | |
| 7W0131 | STUD-DRIVE | 3 | |
| 1N3557 | 9 RING-SEAL | 1 | |
| 4W1223 | 10 SHAFT AS-TURBINE | 1 | |
| 1N3505 | 11 SPACER-THRUST | 1 | |
| 1N3411 | 12 LOCKNUT-TURBOCHARGER (7/16-20-THD) | 1 | |
| 7E9490 | 13 HOUSING AS-BEARING | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 1N3593 | KIT-BEARING (STANDARD) | 1 | |
| 4W4832 | KIT-BEARING (0.25-MM OS) | ||
| 4W4833 | KIT-BEARING (0.25-MM US) | ||
| 4W4834 | KIT-BEARING (0.25-MM OS, 0.25-MM US) | ||
| 1089342 | KIT-CARTRIDGE (TURBOCHARGER) | 1 |
