System And Components
108-3593 COVER GP-AFTERCOOLERS/N 38S16484-UP
Group No: 108-3593
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7428 | 1 PLUG-PIPE (1/4-18-THD) | 1 | |
| 6V3365 | 2 SEAL-LIP TYPE | 2 | |
| 8T9394 | 3 BOLT-SOCKET HEAD (10-24X0.5-IN) | 4 | |
| 9X8256 | 4 WASHER (6.6X12X2-MM THK) | 4 | |
| 1054826 | 5 COVER | 1 | |
| 1055135 | 6 SHAFT-SHUTOFF | 1 | |
| 1056036 | 7 PLATE-SHUTOFF | 2 | |
| 1060740 | 8 BEARING | 4 | |
| 0S1588 | 9 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1615 | 10 BOLT (1/4-20X0.75-IN) | 2 | |
| 2R0364 | 11 RING-RETAINING | 2 | |
| 4N3329 | 12 WASHER (16.25X25.65X0.79-MM) | 2 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P8247 | 14 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 9G2308 | 15 LEVER | 1 | |
| 1056158 | 16 BRACKET | 1 | |
| 1056159 | 17 BUSHING | 1 | |
| 1056625 | 18 SPRING | 1 |
