System And Components
192-5175 LINES GP-AIRS/N 38S16484-UP
Group No: 192-5175
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1228432 | 1 ELBOW-EXHAUST | 1 | |
| 1228433 | 2 ELBOW-EXHAUST | 1 | |
| 8N0879 | 3 CLAMP | 4 | |
| 6I2855 | 4 TUBE AS (EXHAUST)(RH) | 1 | |
| 1332232 | 5 TUBE AS (EXHAUST)(LH) | 1 | |
| 6N7152 | 8 SUPPORT-ELBOW | 1 | |
| 6N7149 | 9 SUPPORT-ELBOW | 1 | |
| 3N3368 | 10 PIPE-EXHAUST | 1 | |
| 1W7515 | 11 COUPLING | 2 | |
| 1A5183 | 12 BOLT (3/8-16X4.75-IN) | 3 | |
| 6N6733 | 13 SUPPORT-HOUSING (LH) | 1 | |
| 6N6734 | 14 SUPPORT-HOUSING (RH) | 1 | |
| 4N1849 | 15 TUBE-AIR | 2 | |
| 5P5700 | 16 SEAL-O-RING | 8 | |
| 4N8523 | 17 PIPE-OUTLET (LH) | 1 | |
| 4N8677 | 18 PIPE-OUTLET (RH) | 1 | |
| 0S1587 | 19 BOLT (1/2-13X1.75-IN) | 4 | |
| 0S1591 | 20 BOLT (3/8-16X1.5-IN) | 4 | |
| 2M8411 | 21 STUD-TAPERLOCK | 1 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 3 | |
| 1A2029 | 23 BOLT (3/8-16X1.125-IN) | 2 | |
| 0L1143 | 24 BOLT (3/8-16X2.5-IN) | 6 | |
| 9F8999 | 25 BOLT (3/8-16X7-IN) | 1 | |
| 3B1915 | 26 BOLT (3/8-16X1.375-IN) | 8 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 4J4382 | 28 PLUG-PIPE (1/2-14-THD) | 2 | |
| 2458342 | 29 GASKET | 2 | |
| 5B7890 | 30 PLUG-PIPE | 2 | |
| 1A5964 | 31 BOLT (3/8-16X4.5-IN) | 1 | |
| 0S1619 | 32 BOLT (3/8-16X3-IN) | 4 | |
| 1F7958 | 33 NUT-FULL (1/2-13-THD) | 4 | |
| 5B2638 | 34 BOLT (3/8-16X5.25-IN) | 2 | |
| 8S9191 | 35 BOLT (3/8-16X4-IN) | 2 |
