System And Components
1N-3726 LINES GP-AIRS/N 38S16484-17823
Group No: 1N-3726
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 8 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 4N2564 | 3 GASKET | 1 | |
| 4N2565 | 4 PLATE-MANIFOLD | 1 | |
| 3J5389 | 5 PLUG (EXTERNAL) | 1 | |
| 5M6213 | 6 PLUG-PIPE (1/4-18-THD) | 3 | |
| 0S1591 | 7 BOLT (3/8-16X1.5-IN) | 4 | |
| 4L8337 | 8 SEAL-O-RING | 2 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 2 | |
| 2S6160 | WASHER-HARD (10.2X32X5-MM THK) | 2 | |
| 7N2445 | 10 PIPE-AIR TRANSFER | 1 | |
| 9N1081 | 11 ADAPTER-TRANSFER PIPE | 1 | |
| 6N2331 | 12 GASKET | 1 | |
| 5L8854 | 13 RING-SEALING | 2 | |
| 5L9738 | 14 COUPLING-EXHAUST | 1 | |
| 9N1865 | 15 SUPPORT-EXHAUST PIPE | 1 | |
| 2N2765 | 16 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 2 | |
| 2N2766 | 17 LOCKNUT (3/8-16-THD) | 6 | |
| 9N5421 | 18 MANIFOLD | 1 | |
| 5B7890 | 19 PLUG-PIPE | 2 | |
| 8N0879 | 20 CLAMP | 4 | |
| 7E3901 | 21 TUBE (EXHAUST) | 1 | |
| 7E3905 | 22 TUBE-EXHAUST | 1 | |
| 1W0481 | 23 RING-EXHAUST SEAL | 2 | |
| 5S1188 | 24 SEAL-O-RING | 2 | |
| 8N0878 | 25 CLAMP | 2 | |
| 8N0886 | SEAL-EXHAUST | 2 | |
| 6L8562 | 26 STUD-TAPERLOCK (3/8-16X1.77-IN) | 4 | |
| 0L2070 | 27 BOLT (3/8-16X2.25-IN) | 4 | |
| 8S9191 | 28 BOLT (3/8-16X4-IN) | 1 | |
| 1N3728 | 29 SPACER | 1 | |
| 6L1650 | 30 SEAL-O-RING | 1 | |
| 9N6472 | 31 SUPPORT-MANIFOLD | 1 | |
| 7E3904 | 32 TUBE | 1 | |
| 7E3903 | 33 TUBE | 1 | |
| 5P5855 | 34 BOLT-12 POINT HEAD (1/2-13X1.75-IN) | 2 | |
| 2M0849 | WASHER-HARD (13.5X25.5X5-MM THK) | 2 | |
| 2W0796 | SUPPORT-EXHAUST PIPE | 1 | |
| 0S1590 | 35 BOLT (3/8-16X2-IN) | 1 |
